5.5 Kw Main Motor Power Color Steel Roof Wall Panel Roll Forming Machine For Roofing
5.5 Kw Main Motor Power Color Steel Roof Wall Panel Roll Forming Machine For Roofing
5.5 Kw Main Motor Power Color Steel Roof Wall Panel Roll Forming Machine For Roofing
5.5 Kw Main Motor Power Color Steel Roof Wall Panel Roll Forming Machine For Roofing
5.5 Kw Main Motor Power Color Steel Roof Wall Panel Roll Forming Machine For Roofing
5.5 Kw Main Motor Power Color Steel Roof Wall Panel Roll Forming Machine For Roofing
5.5 Kw Main Motor Power Color Steel Roof Wall Panel Roll Forming Machine For Roofing
5.5 Kw Main Motor Power Color Steel Roof Wall Panel Roll Forming Machine For Roofing
Specifications
Place of Origin :
China
Brand Name :
TECHWELL
Certification :
CE
Model Number :
TW-RWM
MOQ :
1 Set
Price :
Contact Us
Packaging Details :
Standard packing
Delivery Time :
55-65 working days
Payment Terms :
40% T/T in advance, 60% T/T before shipment
Supply Ability :
20 sets
Description


5.5 Kw Main Motor Power Color Steel Roof Wall Panel Roll Forming Machine For Roofing

Main Specifications of Roof Wall Panel Roll Forming Machine

  • Material thickness: 0.3-0.8mm
  • Material width: depend on customer’s requirement
  • Decoiler Type: manual or automatical type ( depend on customer’s requirement )
  • Weight Capacity Of Decoiler: 5 Ton
  • Main Motor Power: 5.5 Kw
  • Hydraulic Motor Power: 3 Kw
  • Forming Station: 13-20 ( depend on profile drawing )
  • Material of Roller: High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface.
  • Main Axis Material: High grade 45#, quenched and heat treatment.
  • Axis Diameter: ¢ 76mm
  • Working Speed: 0-15 m/min
  • Transporting Type: Chain Transmission
  • Heat Treatment of Cutting Blade: HRC 50-60
  • Type of Cutting: Hydraulic cutting
  • Material Of Cutting Blade: C r 12
  • Heat Treatment of Cutting Blade: HRC 50-60
  • Machine Frame stand: Welded structural steel
  • Thickmess of Fame Steel: 18mm
  • Electrical Control: PLC Frequency Control System with touch screen
  • PLC: PANASONIC Brand
  • Machine Weight: about 5 Ton


Main Components

Decoiler / Uncoiler 1 Unit
Feeding Guide 1 Unit
Roof Wall Panel Roll Forming Machine 1 Unit
Hydraulic Cutting System 1 Unit
Hydraulic Station 1 Unit
PLC Computer Control Box 1 Unit
Support Tables 2 Units


Reference Drawings

5.5 Kw Main Motor Power Color Steel Roof Wall Panel Roll Forming Machine For Roofing
5.5 Kw Main Motor Power Color Steel Roof Wall Panel Roll Forming Machine For Roofing

Applications

Roof Wall Panel, Trapezoidal roof panel, trapezoidal sheet, trapezoidal roof metal, trapezoidal roofing, metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding

Machine Pictures

5.5 Kw Main Motor Power Color Steel Roof Wall Panel Roll Forming Machine For Roofing
5.5 Kw Main Motor Power Color Steel Roof Wall Panel Roll Forming Machine For Roofing

5.5 Kw Main Motor Power Color Steel Roof Wall Panel Roll Forming Machine For Roofing
