Specifications
Place of Origin :
China
Brand Name :
TECHWELL
Certification :
CE
Model Number :
TW-RWM
MOQ :
1 Set
Price :
Contact Us
Packaging Details :
Standard packing
Delivery Time :
55-65 working days
Payment Terms :
40% T/T in advance, 60% T/T before shipment
Supply Ability :
20 sets
Forming Speed :
0-20m/min
Material Thickness :
0.3-0.7mm
Cutting Power :
3.0KW
Cutter Material :
CR12Mov Mold Steel, With Quench Treatment
Forming Roller Material :
45# Steel, coated with hard chrome 0.05mm
Forming Roller Stations :
22-24 forming stations
Description

Chromadek IBR Roof Panel Roll Forming Machine With 0 - 15 m/min Working Speed

Main Specifications of IBR Roof Panel Roll Forming Machine

Item IBR Roof Panel Roll Forming Machine
Coil Material Thickness 0.3-0.8mm
Coil width Custom-made, 925mm or 940mm
Yield Strength 250-350 Mpa
Material PPGI, Color Steel, GI.
Decoiler / Uncoiler Decoiler Type Manual or Hydraulic or Auto Type
Coil Width Max. 1250mm
I.D 508-610mm
O.D Max. 1500mm
IBR Roof Panel Roll FormingMachine Forming Stations 18 Stations ( Depend on Profiles )
Roller material 45# steel, surface coated with 0.05mm hard chrome
Diameter of shaft 76mm
Shaft material High grade 45# steel
Drive type Chain transmission
Forming speed 0-15m/min
Main power 5.5KW
Cutting Device Cutting type Hydraulic cutting
Cutting Die Material Cr12Mov steel, HRC58-62
Cutting power 3KW
CuttingTolerance 10m+/-1.5mm
Encoder OMRON Brand
Electrical Control System PLC PANASONIC Brand
Inverter YASKAWA Brand
Touch screen PANASONICE
Operation type Touch screen & Button
Hydraulic Station Hydraulic station Famous Chinese brand
Runout Table Table type Simple nonpower type
Function To support the finished panels

Main Components of IBR Panel Roll Forming Machine

Decoiler / Uncoiler 1 Unit
Feeding Guide 1 Unit
IBR Roof Panel Roll Forming Machine 1 Unit
Hydraulic Cutting Part 1 Unit
Hydraulic Station 1 Unit
PLC Computer Control Box 1 Unit
Runout Table 2 Units

Reference IBR Roof Drawings

Chromadek IBR Roof Panel Roll Forming Machine With 0 - 15 m/min Working Speed

Chromadek IBR Roof Panel Roll Forming Machine With 0 - 15 m/min Working Speed

Chromadek IBR Roof Panel Roll Forming Machine With 0 - 15 m/min Working Speed

Applications

IBR Roof Panel, IBR Sheets, IBR Roofing, IBR Sheeting, Trapezoidal roof panel, trapezoidal sheet, trapezoidal roof metal, trapezoidal roofing, metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding

Our Advantage

  • Copra designing software
  • 5-8 technicians every month specially do international installation and debugging
  • High Quality
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience

IBR Roof Panel Forming Machine Pictures

Chromadek IBR Roof Panel Roll Forming Machine With 0 - 15 m/min Working Speed
