6 - 8m/min Forming Speed Taper Roof Panel Roll Forming Machine for Tapered Bemo Panel
6 - 8m/min Forming Speed Taper Roof Panel Roll Forming Machine for Tapered Bemo Panel
Specifications
Place of Origin :
China
Brand Name :
TECHWELL
Certification :
CE
Model Number :
TW-STM400
MOQ :
1 Set
Price :
Contact Us
Packaging Details :
Standard packing
Delivery Time :
55-65 working days
Payment Terms :
40% T/T in advance, 60% T/T before shipment
Supply Ability :
20 sets
Description


6 - 8m/min Forming Speed Taper Roof Panel Roll Forming Machine for Tapered Bemo Panel

Main Specifications of Tapered Roof Panel Roll Forming Machine

  • Material thickness: 1mm
  • Decoiler: Manual or hydraulic decoiler
  • Weight capacity of uncoiler: 5 Ton
  • Forming Speed of Tapered Roof Panel Forming Machine: 0-15m/min
  • Forming Station: 16 stations
  • Drive: Chain transmission
  • Main power: 5.5KW
  • Cutting: Hydraulic cutting
  • Cutter material: Cr12Mov, Quenched HRC58-62
  • PLC: Panasonic Brand
  • Support table: Simple Nonpower type
  • Machine weight: about 6Ton
  • Electrical Control: PLC Frequency Control System with touch screen
  • PLC: PANASONIC Brand
  • Encoder: OMRON Brand
  • Transducer: PANASONIC Brand

Working Flow of Tapered Roof Panel Forming Machine


Decoiler -> Slitting & Cutting -> Feeding -> Roll Forming For One Side -> Roll Forming For The Other Side -> Roll Forming For the Middle Rib -> Runout Table

Reference Drawings

6 - 8m/min Forming Speed Taper Roof Panel Roll Forming Machine for Tapered Bemo Panel

6 - 8m/min Forming Speed Taper Roof Panel Roll Forming Machine for Tapered Bemo Panel

6 - 8m/min Forming Speed Taper Roof Panel Roll Forming Machine for Tapered Bemo Panel

6 - 8m/min Forming Speed Taper Roof Panel Roll Forming Machine for Tapered Bemo Panel

Machine Picture

6 - 8m/min Forming Speed Taper Roof Panel Roll Forming Machine for Tapered Bemo Panel

6 - 8m/min Forming Speed Taper Roof Panel Roll Forming Machine for Tapered Bemo Panel

6 - 8m/min Forming Speed Taper Roof Panel Roll Forming Machine for Tapered Bemo Panel

6 - 8m/min Forming Speed Taper Roof Panel Roll Forming Machine for Tapered Bemo Panel

Contact Us freely

Company Wuxi Techwell Machinery Co.,LTD
Website www.cold-rollformingmachine.com
www.roofrollformingmachine.com
www.wxtechwell.com
Video www.youtube.com/wxtechwell
Tel / Fax 0086-510-83133431
Mobile 0086-18018304331 ( Miss Lee )
E-Mail monica@wxtechwell.com
Skype monica198614
MSN lixiaohua_monica@hotmail.com
