Steel Frame C Z Purlin Forming Machine Cold Roll 11KW
Steel Frame C Z Purlin Forming Machine Cold Roll 11KW
Specifications
Brand Name :
TECHWELL
Model Number :
TW-GDA008
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 Set
Price :
Contact Us
Payment Terms :
40% T/T in advance, 60% T/T before shipment
Supply Ability :
20 sets
Delivery Time :
55-65 working days
Packaging Details :
Standard packing
Material :
Galvanized Steel, Carbon Steel
PLC :
Panasonic Brand
Roller Material :
GCr15 Steel, Surface Coated With 0.05mm Hard Chrome
Drive Type :
Chain drive
Main Power :
11KW
Punching Type :
Hydraulic punching
Description

Steel Frame C Z Purlin Cold Roll Forming Machine

Main Technical Parameters of Guide Rail Roll Former

Coil Material Galvanized steel, carbon steel
Material Thickness 1.5-3.0mm
Decoiler Type Manual or Hydraulic or Auto type
Coil I.D 508-610mm
Forming Stations About 16 stations (Depend on profiles)
Roller Material GCr15 steel, surface coated with 0.05mm hard chrome
Axis of Diameter 80mm
Shaft Material High grade 45# steel
Drive Type Chain drive
Forming Speed 0-15m/min (Not including cutting)
Main Power 15 KW
Punching Type Hydraulic punching
Punching Mold Size According to drawing
Cutting Hydraulic cutting
Cutting Die Material Cr12Mov
Cutting Tolerance +/-1.5mm
PLC Panasonic
Inverter YASKAWA
Touch Screen Panasonic
Operation Type Touch screen & Button

Working Flow Chart

Decoiler --- Feeding and Leveling --- Main Roll Forming --- Hydraulic Punching --- Cut-to-length ---

Run out Table

Main Components

  • Decoiler / Uncoiler -------------------------------------------------------1 Unit
  • Feeding & Leveling Device --------------------------------------------1 Unit
  • Main Roll Forming Machine --------------------------------------------1 Unit
  • Hydraulic Punching Device ---------------------------------------------1 Unit
  • Cutting Device-------------------------------------------------------------1 Unit
  • Hydraulic Station----------------------------------------------------------1 Unit
  • PLC Electrical Control Board ------------------------------------------1 Unit
  • Run-out Table-------------------------------------------------------------1 Unit

Reference Profile Drawing

Steel Frame C Z Purlin Forming Machine Cold Roll 11KW
Steel Frame C Z Purlin Forming Machine Cold Roll 11KW
Steel Frame C Z Purlin Forming Machine Cold Roll 11KW

Applications

Elevator guide rail, door frame guide rail, curtain track, shutter door slats guide

Competitive Advantages

  • High Quality
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience
