Cold Room Unit Cooler Evaporator Electric Defrost Blast Freezer Room Evaporator
Cold Room Unit Cooler Evaporator Electric Defrost Blast Freezer Room Evaporator
Cold Room Unit Cooler Evaporator Electric Defrost Blast Freezer Room Evaporator
Cold Room Unit Cooler Evaporator Electric Defrost Blast Freezer Room Evaporator
Specifications
Brand Name :
DM
Model Number :
DM-0006
Place of Origin :
China
Certification :
CE ISO
MOQ :
1
Price :
1000-100000
Packaging Details :
Customization
Delivery Time :
20day
Payment Terms :
TT L/C
Supply Ability :
300000/Year
Name :
Unit Cooler Evaporator
Operating Cycle :
Long
Cold Room Type :
Blast Freezer
Evaporating Area :
7-180 Square Meter
Defrost Type :
Electric
Temperature :
High, Medium, Low Temperature
Expansion Valve :
Danfoss
Refrigerant :
R404a
Fan Type :
Axial
Ss Casing :
optional
Air Cooler :
Yes
Hs Code :
8418951000
Color :
paint as customers needs
Key Words :
Air Cooler
Type :
Evaporative Air Cooler
Product Type :
Cold Storage (Cold Room)
Case Material :
stainless steel or steel
Defrost :
Electrical type
Gas :
R404A
Standard Power Supply :
380V-3phase-50hz
Description

Maximize Your Industrial Cooling Efficiency with Our Advanced Cold Room Evaporator

Product Description:

Our unit coolers/evaporators can be widely used in various kinds of preserved and refrigeration cold-rooms, food processing workshops and distribution centers. Our compact and reliable design can help customers optimise the space. When match with low noise axial fan, you can rapidly reduce noise level of working space and highly increase comfortable level.

Refrigeration capacity of this series covers from 1.2KW to 114KW, fitting with different refrigerant such as R134a·R404A·R507A·R407C·R22.

Cold Room Unit Cooler Evaporator Electric Defrost Blast Freezer Room Evaporator

Features:

Scientific structure, high efficient, frost evenly, save power and bw running cost;

Match with axial fan quiet models that offer strong air flow in long shot rang;power saving, long life cycle;

Lead to perfect tightness between pipe and fin after expansion processing;

Match with stainless electric heater in high insulating property, defrost efficiently in shot time;

The heat exchanging coil pass gas tightness test up to 2.6MPa air pressure;

Aluminum and painted stan board, to meet your different demands.

Sphere of application

High temperature type:

(cold room temperature 12~- 2ºC)fin space:4.5mm;

Medium temperature type:

(cold room temperature-2 ~- 10ºC) fin space:6.0mm;

Low temperature type:

(cold room temperature - 10~-31ºC)fn space:9.0mm;

→Tailor-made for customers

Model Nominal cooling capacity Cooling area Pitch of fins Fan Deforost electrothemal tube
Number Diameter Air volume Wide pressure Range Fan power Moter voltage Coil(kw) Water pond(kw) Voltage(V)
DD-1.4/7 1400(1200) 7 6.0 1 ∅300 1700 98(10) 8 90 380 0.9 0.4 220
DD-2.35/12 2350(2000) 12 6.0 2 ∅300 2×1700 98(10) 8 2×90 380 1.2 0.4 220
DD-3.0/15 3000(2600) 15 6.0 2 ∅300 2×1700 98(10) 8 2×90 380 1.35 0.45 220
DD-4.0/22 4000(3450) 21.5 6.0 3 ∅300 3×1700 98(10) 8 3×90 380 1.8 0.6 220
DD-6.0/30 6000(5150) 30 6.0 2 ∅400 2×3000 118(120) 12 2×216 380 2.6 1.3 220
DD-8.0/40 8000(6900) 40 6.0 2 ∅400 2×3000 118(120) 12 2×216 380 2.8 1.4 220
DD-12.0/60 12000(10300) 60 6.0 2 ∅500 2×6000 167(17) 15 2×550 380 6.0 1.5 220
DD-15.9/80 15900(13700) 80 6.0 2 ∅500 2×6000 167(17) 15 2×550 380 7.5 1.5 220
DD-20.0/100 20000(17200) 100 6.0 3 ∅500 3×6000 167(17) 15 3×550 380 9.5 1.9 220
DD-24.0/120 24000(20650) 120 6.0 3 ∅500 3×6000 167(17) 15 3×550 380 11.0 2.2 220
DD-28.0/140 28000(24100) 140 6.0 4 ∅500 4×6000 167(17) 15 4×550 380 12 2.4 220
DD-32.1/160 32100(27600) 160 6.0 4 ∅500 4×6000 167(17) 15 4×550 380 12.5 2.5 220
DD-37.4/200A 37400(32200) 200 6.0 4 ∅500 4×6000 167(17) 15 4×550 380 13.5 2.7 220
DD-37.4/200B 37400(32200) 201 6.0 2 ∅600 2×10000 200 18 2×1100 380 15.2 1.9 220
DD-46.8/250 46800(40300) 256 6.0 3 ∅600 3×10000 200 18 3×1100 380 17.6 2.2 220
DD-56.2/310 56200(48300) 307 6.0 3 ∅600 3×10000 200 18 3×1100 380 20 2.5 220
DD-67.0/372 67000(57620) 372 6.0 3 ∅600 3×12000 240 20 3×1500 380 23 2×2.3 220
DD-81.5/450 81500(70090) 450 6.0 3 ∅700 3×15000 290 25 3×2200 380 2703 2×2.1 220
DD-99.6/530 99600(85650) 525 6.0 3 ∅700 3×15000 290 25 3×2200 380 31.2 2×2.4 220

Applications:

There are many types of cold storage facilities available to meet a variety of needs. These include:

  • Freezer rooms
  • Blast freezers
  • Cold storage warehouses
  • Meat cold storage facilities
  • Fruit and vegetable storage rooms
  • Seafood storage rooms
  • Display cold rooms
  • Chiller rooms
  • Logistics cold storage warehouses

Each of these facilities is designed to meet specific requirements for temperature, humidity, and airflow. Freezer rooms, for example, are typically maintained at temperatures of -18 degrees Celsius or lower, making them suitable for long-term storage of frozen goods like meat and seafood. Meanwhile, blast freezers are capable of rapidly cooling products to very low temperatures, making them ideal for items that need to be frozen quickly to retain freshness and quality.

Other facilities like chiller rooms and display cold rooms are used to store and display chilled products like dairy, ready-to-eat meals, and beverages. These rooms must maintain a consistent temperature to ensure product safety and quality.

In addition to food storage, cold storage facilities are also used for pharmaceuticals, chemicals, and other temperature-sensitive products. Overall, the availability of different types of cold storage facilities allows businesses to choose the appropriate storage solution for their unique needs.


Cold Room Unit Cooler Evaporator Electric Defrost Blast Freezer Room EvaporatorCold Room Unit Cooler Evaporator Electric Defrost Blast Freezer Room Evaporator

Cold Room Unit Cooler Evaporator Electric Defrost Blast Freezer Room EvaporatorCold Room Unit Cooler Evaporator Electric Defrost Blast Freezer Room Evaporator

Customization:

Brand Name: DM

Model Number: DM-0006

Place of Origin: China

Certification: CE ISO

Minimum Order Quantity: 1

Price: 1000-100000

Packaging Details: Customization

Delivery Time: 20day

Payment Terms: TT L/C

Supply Ability: 300000/Year

Fan Diameter: 300-630mm

Cold Room Type: Blast Freezer

Fin Spacing: 4.5-10mm

Series: SDL/SDD

Operating Cycle: Long

Keywords: Commercial Evaporative Air Cooler, Air Cooled Evaporator, Air Cooled Evaporator

Support and Services:

The Cold Room Evaporator product technical support and services include:

- Assistance with installation and setup of the product.

- Troubleshooting assistance for any issues that may arise with the product.

- Maintenance and repair services to keep the product functioning properly.

- Technical documentation and manuals for the product.

- Training and educational resources for customers and technicians.

- Warranty support and replacement parts for any defective components.

Packing and Shipping:

Product Packaging:

  • The cold room evaporator will be packed securely in a cardboard box.
  • The box will be labeled and marked with the product name and specifications.
  • Inside the box, the evaporator will be wrapped with protective materials to prevent any damage during shipping.
  • The packaging will also include an instruction manual and warranty information.

Shipping:

  • The product will be shipped via a reliable courier service.
  • The shipping cost will be calculated based on the destination and weight of the package.
  • Customers will receive a tracking number once the product is shipped.
  • The estimated delivery time will depend on the customer's location and the courier's delivery schedule.

Cold Room Unit Cooler Evaporator Electric Defrost Blast Freezer Room EvaporatorCold Room Unit Cooler Evaporator Electric Defrost Blast Freezer Room EvaporatorCold Room Unit Cooler Evaporator Electric Defrost Blast Freezer Room EvaporatorCold Room Unit Cooler Evaporator Electric Defrost Blast Freezer Room Evaporator

FAQ:

Q: Where is this cold room evaporator made?

A: This cold room evaporator is made in China.

Q: What certifications does this cold room evaporator have?

A: This cold room evaporator has CE and ISO certifications.

Q: What is the minimum order quantity for this cold room evaporator?

A: The minimum order quantity for this cold room evaporator is 1.

Q: What is the price range for this cold room evaporator?

A: The price range for this cold room evaporator is between 1000-100000.

Q: What are the packaging details for this cold room evaporator?

A: The packaging details for this cold room evaporator are customizable.

Q: What is the delivery time for this cold room evaporator?

A: The delivery time for this cold room evaporator is 20 days.

Q: What are the payment terms for this cold room evaporator?

A: The payment terms for this cold room evaporator are TT and L/C.

Cold Room Unit Cooler Evaporator Electric Defrost Blast Freezer Room Evaporator
