Customized Cold Room Evaporator For Chemical Industry / Light Industry
Customized Cold Room Evaporator For Chemical Industry / Light Industry
Customized Cold Room Evaporator For Chemical Industry / Light Industry
Customized Cold Room Evaporator For Chemical Industry / Light Industry
Specifications
Brand Name :
DM
Model Number :
DM-0006
Place of Origin :
China
Certification :
CE ISO
MOQ :
1
Price :
1000-100000
Packaging Details :
Customization
Delivery Time :
20day
Payment Terms :
TT, L/C
Supply Ability :
300000/Year
Evaporating Area :
7-180 Square Meter
Fan Diameter :
300-630mm
Business Type :
RD & manufacturing factory
Capacity :
2.4KW
Cold Room Type :
Blast Freezer
Operating Cycle :
Long
Fan Qty :
1-4
Material Of Fin :
aluminum
Fin Distance :
4.5mm or customized
Ai Flow :
46000CMH
Power :
all available
Widely Used :
Chemical industry, light industry
Frame :
Stainless Steel, galvanized steel
Casing :
steel plate with plastic spray
Case Material :
stainless steel or steel
Fin Color :
Black
Name :
Cold Room Evaporator
Description

Upgrade Your Cooling System With Our Customizable Cold Room Evaporator

Product Description:

Characteristics

Scientific structure, high efficient, frost evenly, save power and bw running cost;

Match with axial fan quiet models that offer strong air flow in long shot rang;power saving, long life cycle;

Lead to perfect tightness between pipe and fin after expansion processing;

Match with stainless electric heater in high insulating property, defrost efficiently in shot time;

The heat exchanging coil pass gas tightness test up to 2.6MPa air pressure;

Aluminum and painted stan board, to meet your different demands.

Customized Cold Room Evaporator For Chemical Industry / Light Industry

Features:

Scientific Structure for Efficient and Cost-Effective Frosting

Our product is designed with a scientific structure that guarantees high efficiency and even frost distribution. By doing so, we help our customers save on running costs and power consumption.

Axial Fan Quiet Models for Strong Airflow

In addition, our product is paired with axial fan quiet models that provide a strong gust of air flow over a long range. Not only do these fans save on power consumption, but they are also crafted with a long life cycle.

Perfect Tightness for Better Performance

When it comes to pipe and fin compatibility, we have you covered. Our expansion processing technique leads to a tight and perfect seal between the two, ensuring that our product always functions at its best.

Efficient Defrosting for Optimal Performance

Our product also pairs well with a stainless electric heater with high insulating properties. Not only does this material help with defrosting, but it does so quickly and efficiently.

Gastight Coil for Added Durability

Additionally, our heat exchanging coil passes a gastightness test up to 2.6MPa air pressure, guaranteeing added durability and longevity for our product.

Flexible Material for Versatile Application

Finally, our product is crafted using both aluminum and painted stan board, making it a versatile choice to meet your various demands. It's suitable for a wide range of applications and environments.

Sphere of Application

Our product can be used in a variety of settings, such as refrigeration and air conditioning units for commercial buildings, schools, hospitals, data centers, and more.

Model Nominal cooling capacity Cooling area(㎡) Pitch of fins(㎜) Fan Water volume(T/h) Water inlet tube diameter Water outlet pipe diameter
Number Diameter Air volume Wide pressure Motor(W) Voltage(V)
DLS-16.7/80 16700(14350) 80 4.5 2 ∅500 2×6000 167 2*550 380 2.1 1″ 2″
DLS-22.0/105 22000(18900) 105 4.5 2 ∅500 2×6000 167 2*550 380 2.8 1″ 2″
DLS-25.8/125 25800(22200) 125 4.5 3 ∅500 3×6000 167 3*550 380 3.5 1½″ 3″
DLS-33.6/160 33600(28900) 160 4.5 3 ∅500 3×6000 167 3*550 380 4.2 1½″ 3″
DLS-38.7/185 38700(33300) 185 4.5 4 ∅500 4×6000 167 4*550 380 4.9 1½″ 3″
DLS-44.0/210 44000(37850) 210 4.5 4 ∅500 4×6000 167 4*550 380 5.6 1½″ 3″
DLS-52.9/260A 52900(45500) 256 4.5 4 ∅500 4×6000 167 4*550 380 7.0 1½″ 3″
DLS-52.9/260B 52900(45500) 258 4.5 2 ∅600 2×10000 200 2*1100 380 7.0 1½″ 3″
DLS-67.2/330 67200(57800) 326 4.5 3 ∅600 3×10000 200 3*1100 380 8.75 2″ 4″
DLS-83.4/410 83400(71700) 407 4.5 3 ∅600 3×10000 200 3*1100 380 10.85 2″ 4″
DLS-101.7/500 101700(87460) 496 4.5 3 ∅600 3×12000 240 3*1500 380 13.1 2″ 4″
DLS-122.0/600 122000(104900) 604 4.5 3 ∅700 3×18000 290 3*2200 380 15.7 2″ 4″
DLS-142.3/700 142300(122370) 700 4.5 3 ∅700 3×18000 290 3*2200 380 18.5 2″ 4″

Technical Parameters:

Temperature Range for Different Purposes

Nature can be beneficial in many aspects of our lives. One of the ways in which we can utilize nature is by understanding the suitable temperature range for different purposes. Below are the different temperature ranges for various purposes.

Fruit Ripening

The temperature range for fruit ripening is above 25C. This means that if you want to ripen fruits, the room or storage area should be kept at a temperature above 25C.

Processing Room

The temperature range for a processing room is between 12-19C. This means that if you are processing food, the temperature inside the room should be kept between 12-19C.

Fruit, Vegetable, Dry Food

The temperature range for storing fruit, vegetables, and dry food is between -5 to +10C. This means that if you want to store any of these items, the temperature of the storage area should be in this range.

Medicine, Cake, Pastry, Chemical Material

The temperature range for storing medicine, cake, pastry, and chemical material is between 0C to -5C. This means that if you want to store any of these items, the temperature of the storage area should be kept between 0C to -5C.

Ice Storage Room

The temperature range for storing ice is between -5 to -10C. This means that if you want to store ice, the temperature of the storage area should be kept between -5 to -10C.

Fish, Meat Storage

The temperature range for storing fish and meat is between -18 to -25C. This means that if you want to store fish or meat, the storage area should be kept between -18 to -25C.

Deep Freezer, Low Temperature Storage, Quick-Freeze, Blast Freezer

The temperature range for deep freezer, low temperature storage, quick-freeze, and blast freezer is between -25C to -40C. This means if you need to store anything in these types of freezers, they should be kept between -25C to -40C.

Customized Cold Room Evaporator For Chemical Industry / Light Industry

Support and Services:

The Cold Room Evaporator product technical support and services include:

  • Installation guidance and support
  • Product training and orientation
  • Maintenance and troubleshooting assistance
  • Replacement parts and accessories
  • Extended warranty options
  • 24/7 customer service and technical support

Customized Cold Room Evaporator For Chemical Industry / Light IndustryCustomized Cold Room Evaporator For Chemical Industry / Light IndustryCustomized Cold Room Evaporator For Chemical Industry / Light IndustryCustomized Cold Room Evaporator For Chemical Industry / Light Industry

Packing and Shipping:

Product Packaging for Cold Room Evaporator:

  • The evaporator will be packed securely in an appropriate-sized box.
  • The box will be labeled with the product name, description, and quantity.
  • The box will be sealed with strong packing tape to prevent any damage during shipping.

Shipping Information for Cold Room Evaporator:

  • The product will be shipped within 2 business days of order confirmation.
  • We use reliable and trusted shipping carriers to ensure your product arrives safely and on time.
  • You will receive a tracking number via email once your order has shipped.
  • Please inspect the product upon delivery and contact us immediately if there are any issues.
Customized Cold Room Evaporator For Chemical Industry / Light IndustryCustomized Cold Room Evaporator For Chemical Industry / Light IndustryCustomized Cold Room Evaporator For Chemical Industry / Light IndustryCustomized Cold Room Evaporator For Chemical Industry / Light Industry

FAQ:

Q: What certifications does this Cold Room Evaporator have?

A: This Cold Room Evaporator is certified with CE and ISO.

Q: What is the minimum order quantity for this Cold Room Evaporator?

A: The minimum order quantity for this Cold Room Evaporator is 1 unit.

Q: What is the price range for this Cold Room Evaporator?

A: The price range for this Cold Room Evaporator is between $1000 and $100000.

Q: What are the packaging details for this Cold Room Evaporator?

A: The packaging details for this Cold Room Evaporator can be customized.

Q: What is the delivery time for this Cold Room Evaporator?

A: The delivery time for this Cold Room Evaporator is 20 days.

Q: What are the payment terms for this Cold Room Evaporator?

A: The payment terms for this Cold Room Evaporator are TT and L/C.

Q: What is the supply ability for this Cold Room Evaporator?

A: The supply ability for this Cold Room Evaporator is 300000 units per year.
