Custom Air Cooled Cooling Coil / Condenser Or Evaporator Parts Fin And Tube Evaporator
Custom Air Cooled Cooling Coil / Condenser Or Evaporator Parts Fin And Tube Evaporator
Custom Air Cooled Cooling Coil / Condenser Or Evaporator Parts Fin And Tube Evaporator
Custom Air Cooled Cooling Coil / Condenser Or Evaporator Parts Fin And Tube Evaporator
Custom Air Cooled Cooling Coil / Condenser Or Evaporator Parts Fin And Tube Evaporator
Custom Air Cooled Cooling Coil / Condenser Or Evaporator Parts Fin And Tube Evaporator
Specifications
Brand Name :
Ecool
Model Number :
ECC13
Certification :
CE,ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
100 sets/time
Delivery Time :
2-3 weeks
Packaging Details :
suitable for sea shipment in container
Name: :
Custom Air cooled Cooling Coil / Condenser or evaporator Parts/ Fin and Tube evaporator
Size :
as customer request
Coil Materials :
Multiple choice
Materials :
Muiltple options
Application :
AC, industrial condenser
Anti-corrosion :
paint and special treat
Description

Custom Air cooled Cooling Coil / Condenser or evaporator Parts/ Fin and Tube evaporator

1.Cooling coil Application:

Chemical gas condensation, commercial and industrial refrigeration unit, energy recovery system, polluted gas recovery systems

2. Products Advantages

  • Heat exchanger structure: Max. length is 12 meter and max width is 2.7meter.
  • The exchangers are designed to suit for common used refrigerants, Freon R410a, R507a and special refrigerant such as CO2 or secondary refrigerant.
  • The design software is European brand which could design the heat exchanger accurately according to request.
  • We received one set customized sample order

3.Costomized product request form

Cooling coil select 　 　 　 　
Capacity KW 　
Coolant Water other %
Glycol % Propylene glycol %
Liquid Inlet temerature(DB) C 　
Liquid Outlet temperature(DB) C
Flow M3/h
Air flow/Face Velocity M3/h m/s
Air Inlet temperature(DB) C
Air Inlet temperature(WB)/
relative humidity		 C/%
Outlet air temperature C 　
Frame dimension mm L W H

4.Delivery Contents

  • Completed and details data of coil

  • CAD drawing for confirmation and review

  • Customized coils

5.Steps of delivery of cooling coils

  • Beginning stage---Help clients to design and select models, reasonably control cost and offer price to increase client’s bidding rate

  • Confirm stage---Provide accurate design drawing for the confirmation of user, fix the cost to avoid temporary changes

  • Production stage---produce according to the confirmed plan and ensure delivery accurately and quickly

6.The Die specification

No Die type Hole layout Fin space Fin shape Fin edge type Al fin Thickness Cu fin Thickness Stainless steel fin thickness Tube
Flat/inside thread tube Tube external diameter and wall thickness
1 3/8” 25*21.65 equilateral triangle 1.8~7mm

corrugated

Flat+wave

0.12/0.15/

0.175/0.2/0.5

0.12/0.15/0.2

 - inside thread tube Ø9.52*0.30+0.17
flat Ø9.52*0.31/0.75
2 1/2” 31.75*27.5 equilateral triangle 1.8~8mm inside thread tube Ø12.7*0.41+0.25
flat Ø12.7*0.38/0.75
3 5/8” 38.1*33 equilateral triangle 1.8~9mm inside thread tube Ø15.88*0.4+0.25
flat Ø15.88*0.40+0.25

SS304

SS316

Ø15.88*0.6

Ø15.88*0.9
4 5/8” 50*50 square 2.5~12mm corrugated, smooth Flat 0.2/0.25/0.3/0.33 0.15/0.2 0.15/0.2/0.3 inside thread tube Ø15.88*0.41+0.25
Flat Ø15.88*0.41/0.635/0.89

SS304

SS316

Ø15.88*0.6

Ø15.88*0.9
