Low Noise Screw Parallel Refrigeration Compressor Unit For Cold Storage Refrigeration
Low Noise Screw Parallel Refrigeration Compressor Unit For Cold Storage Refrigeration
Low Noise Screw Parallel Refrigeration Compressor Unit For Cold Storage Refrigeration
Low Noise Screw Parallel Refrigeration Compressor Unit For Cold Storage Refrigeration
Specifications
Brand Name :
ECOOL
Model Number :
EPBSL3-60
Certification :
ISO9001; CCC;QS
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiable
Supply Ability :
1000sets per year
Delivery Time :
3-4 weeks
Packaging Details :
wooden case or carton plus wooden tray
Name :
Low Noise Screw Parallel Refrigeration Compressor Unit For Cold Storage Refrigeration
Evaporating Temperature :
-40C~-23C
Condensing Temperature :
35C ~45C
Refrigeration Capacity :
180HP
Warranty :
1Year
Noise :
Low
Compressor qty :
3
Description

Low Noise Screw Parallel Refrigeration Compressor Unit For Cold Storage Refrigeration

Refrigeration unit Specifications

Model Condensing Temp. Cooling capacity(KW) under diff. Evaporating temp. Compressor motor power Receiver size connection pipe size(customized available) Dimension Operating weight
-23 -30 -40 Suction pipe Supply pipe
　 C (kw) (L) (mm) (mm) (L×W×H)mm (kg)
EPBSL3-60 35 263.1

197.7

 123.6 135 200 2*108 54 3538*1325*1785 2600
45 245.1 183 112.2

Refrigeration unit Standard Configuration:

suction line filter, electric cabinet, oil separator, oil cooler, high and low-pressure controller,economizer, injection components,liquid receiver, gauge panel, screw compressor,liquid supply line filer.

Refrigeration unit application
Compressor unit is the main machine for:

  • Large refrigeration system of cold storage, processing warehouse.
  • quick freezer system such as tunnel freezer, channel freezer, spiral freezer.


ECOOL Refrigeration unit advantages
Reliable quality

  • Every product is tested strictly before getting out of factory including vibration test,noise test, performance test to ensure a service life above 15 years.

Worry saving

  • With complete protection system against HP, LP ,overload, overheat etc, the unit could work normally even in very bad conditions
Intelligent
  • Our product doesn't need person to watch the operation, it could turn on and off automatically, adjust the load, record running data, remote control, and fault diagnosis
  • With complete protection system against overload, overheat, HP, LP etc, the unit could work normally even in very bad conditions

Energy saving.

  • Energy saving up to 35%.The design makes the unit automatically change the working numbers of compressor depending on system load, which can save your running cost.

Refrigeration unit VS Site-assembled system

Compressor unit/compressor rack VS Conventional Site-assembled system
Less jobsite labor means lower cost Multiple vendors mean project management and costs
Optimized design means fewer welds More welds equal more cost and time
“Factory Built” controlled environment; site delivered,ready to operate Environmental variation during construction
Simplified electrical hookups Expensive on-site electrician for wiring connections
Freeze protection from 3-Directional expansion Process side uses pumped ammonia
Plate and frame heat exchanger means less
refrigerant charge

Model CodeLow Noise Screw Parallel Refrigeration Compressor Unit For Cold Storage Refrigeration
