Insulation Boards /Sandwich Panel for Cold Storage Wall and Ceiling Density 40Kg/M3
Insulation Boards /Sandwich Panel for Cold Storage Wall and Ceiling Density 40Kg/M3
Insulation Boards /Sandwich Panel for Cold Storage Wall and Ceiling Density 40Kg/M3
Insulation Boards /Sandwich Panel for Cold Storage Wall and Ceiling Density 40Kg/M3
Specifications
Brand Name :
Ecool
Model Number :
EP011
Certification :
ISO9001,CCC,
Place of Origin :
China
MOQ :
1000 square meters
Price :
Negotiable
Supply Ability :
10000 square meter/year
Delivery Time :
3-4 Working weeks
Packaging Details :
Standard Export Package
Key word :
Machin produced panel
Surface :
Color steel, stainless steel, aluminum,galanized steel,without steel
Surface type :
flat/ribs grain/finely-laminated
suiface thickness :
0.4~0.8mm
Max. length :
16meter
Width :
1120mm
Description

Insulation Boards /Sandwich Panel for Cold Storage Wall and Ceiling Density 40Kg/M3


Feature

  • strong resistance to deformation, not easy to crack, stable and safe finish.
  • rigid polyurethane has moisture and water resistance. The rigid polyurethane has a closed cell ratio of more than 90%, and is a hydrophobic material. It does not increase the thermal conductivity due to moisture absorption, and the wall does not seep.
  • polyurethane material porosity structure is stable, basically closed-cell structure, not only excellent thermal insulation performance, but also anti-freeze-thaw, sound absorption. The average life of the rigid foam polyurethane insulation structure can reach more than 30 years under normal use and maintenance conditions. It can be destroyed under normal conditions of use during the life of the structure, dry, wet or galvanic corrosion, and due to external factors such as insects, fungi or algae growth or damage caused by rodents.

Application

besides cold room, our panel could be used for building materials of:

Agricultural / Farm;

Car wash Buildings

Clean Rooms

Disaster / Emerg Shelters

Equipment Sheds / Bldgs

Fire Resistant Rooms

Floral Retail / Storage

Ice Storage / Dispensing

LEEDs Building

Loading Dock Panels

Metal SIPS

Military Field Shelters

Partition Walls

Pharmaceutical Storage

Roof Systems

Transportation Containers

Walkable Ceilings / Roof

Panel information

Type Polyurethane Sandwich Panels
Panel Material Color steel sheet,stainless steel sheet,or emboseed aluminum sheet,galvanized steel sheet,polyurethane sheet.
Place of Origin China
Length Customize
Effective Width 1120mm
Core thickness 50mm,75mm,100mm,120mm,150mm,175mm,200mm,250mm
Features Soundproof, fireproof, waterproof
Certificates SGS, ISO14001, ISO9001,
Color White, Gray, Sliver, Whit gray...etc,as required
Lifetime 10-30 years
Fire proof rate B2 (B1 avaible) B1 is the best


Technical Specifications

The Technical Standard of Eccentric hook panel
No. Item Unit Tel. requirement
1 Density KG/M3 40±2
2 Heat conductivity W/m.k <=0.024
3 Compressive strength >=150 >=150
4 Combustion performance Average burning time S <=90
Average burning range mm <=50
5 The bond strength between sandwich core layer and panel Mpa >0.1
6 Stripping performance The core material on the surface - uniform distribution
The adhesive area of each stripping surface - >=90%


Choose the right thickness for your building

Thickness Suitable indoor temperature
50 ≥ 15°C
75 ≥ 10ºC
100 ≥ -5ºC
150 ≥ -20ºC
200 ≥ -25ºC
250 ≥ -35ºC



Product tags

insulated panel board

,

cold storage panels

,

insulated sandwich panel walling system
