Polyurethane Sandwich Panel For Cold Rooms / Cold Storage Walls 150mm Thickness
Polyurethane Sandwich Panel For Cold Rooms / Cold Storage Walls 150mm Thickness
Specifications
Brand Name :
Ecool
Model Number :
EP0014
Certification :
ISO9001,CCC,
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiable
Supply Ability :
15000000 square meter/year
Delivery Time :
3-4 Working weeks
Packaging Details :
Standard Export Package
Payment Terms :
L/C, T/T
Name :
Sandwich Panel For Cold Rooms
Warranty :
1Year
Application :
Cold Storage
Package :
films
Trade Term :
CNF,FOB,CIF,CIP,EXWORK
Thickness :
150mm
Description

Polyurethane Sandwich Panel For Cold Rooms / Cold Storage Walls 150mm Thickness

Sandwich Panel For Cold Rooms Features

  • good performance in insulation
  • compressive and tensile strength
  • hard to deform.

Sandwich Panel For Cold Rooms Application:

Wall panel and ceiling panel Thermal insulation for cold storage
Core thickness options: 50,75,100,120,150,180,200,250mm

Sandwich Panel For Cold Rooms information:

Type Polyurethane Sandwich Panel For Cold Rooms / Cold Storage Walls 140mm
Protective surface Material Color steel sheet/PPGI
Place of Origin China
Length Customize
Effective Width 1140mm
Core thickness 50mm,75mm,100mm,120mm,150mm,180mm,200mm,250mm
Features Soundproof, fireproof, waterproof
Certificates SGS, ISO14001, ISO9001,
Color Whit grey
Lifetime 10-30 years


Specifications:

No. Item Unit Tel. requirement
1 Density KG/M3 40±2
2 Heat conductivity W/m.k <=0.024
3 Compressive strength >=150 >=150
4 Combustion performance Average burning time S <=90
Average burning range mm <=50
5 The bond strength between sandwich core layer and panel Mpa >0.1
6 Stripping performance The core material on the surface - uniform distribution
The adhesive area of each stripping surface - >=90%


Designed Room temperature and thickness of insulation panel

Thickness Suitable temperature
50 ≥ 15°C
75 ≥ 10ºC
100 ≥ -15ºC
150 ≥ -25ºC
200 ≥ -35ºC
250 ≥ -45ºC

The technical standard

No Surface material Thickness Surface streak

50
mm

75
mm

100
mm

120
mm

150
mm

175
mm

200
mm

250
mm

 Flat Ribs grain Finely laminated
1 Colored steel sheet(0.326-0.8mm) √ √ √ √ √ √ √ √ √ √ √
2 Stainless steel sheet(0.4-0.8mm) √ √ √ √ √ √ √ √ √ √ √
3 Embossed aluminium sheet(0.5-3mm) √ √ √ √ √ √ √ √
4 Galvanized steel sheet (0.5-2mm) √ √ √ √ √ √ √ √ √
5 Polyurethane sheet √ √ √ √ √ √ √ √
