Crash Barrier Roll Forming Machine , Metal Roofing Roll Former With Auto Stacker
Crash Barrier Roll Forming Machine , Metal Roofing Roll Former With Auto Stacker
Crash Barrier Roll Forming Machine , Metal Roofing Roll Former With Auto Stacker
Crash Barrier Roll Forming Machine , Metal Roofing Roll Former With Auto Stacker
Specifications
Brand Name :
FEIXIANG
Model Number :
highway crash barrier Highway Guardrail Roll Forming Machine with auto stacker
Certification :
CE ISO,
Place of Origin :
China
MOQ :
1 sets
Supply Ability :
20 SETS/MONTH
Delivery Time :
45 working days
Packaging Details :
40'GP
Normal thickness :
2-4mm
Type :
highway guardrail forming machine
Control :
Delta Siemens
Station :
as requst
Payment :
T/T L/C
use for :
highway road
Description

Crash Barrier Roll Forming Machine , Metal Roofing Roll Former With Auto Stacker

1. Product Description

Guaranteed Two Waves Highway Guardrail Roll Forming Machine package:Nude,the computer controlling parts packaged with water proof cloth.
Usually the Galvanized Drywall Used Omega Profile Light Gauge Steel Framing Cold Roll Forming Machine can be packed into one 20' feet container or 40' feet container. We have good relationship with the shipping agent. Either you can find the shipping line at your side or we can help you.

2. Machine details

Brand: Feixiang
Model number:Crash Barrier Roll Forming Machine , Metal Roofing Roll Former With Auto Stacker
Voltage requirement: 380v50HZ,3PH
Working speed:15/min

3. Machine composition

No. Name Unit Qty
1 Decoiler set 1
2 Main Machine for roll forming set 1
3 Control System(PLC) set 1
4. Hydraulic oil pump set 1
5. Product stand set 1

Decoiler have manual decoiler,Electric decoiler and Hydraulic decoiler,can booking as request

4. Main parameters

Length of the main part About15500*1650*1500mm
Weight of main part About 9.5 ton
Voltage 380V/50HZ3Phase (as customer`s request)
Roller fixer Middle plate welded
Frame 400H steel welded
Middle plate thickness 30mm
Drive mode Chain Drice//Gear Drive
Material of rollers GCR15, quenched treated HRC58-62℃
Material of shafts 45# steel
Diameter of shafts Φ100mm(depend on defferent design)
Number of rollers: 16 rollers
Main power 37kw
Cutting&Hydraulic Double guide pillar
Hydraulic motor power 15kw
Hydraulic Pressure 10-12MPa
Cutting drive Decelerating motor + Chain drive gear all by high-frequency
Control System PLC system: Mitstubishi, Panasonic,Detal,Siemens,Schneider
Feeding Material width Better as your drawing or from our designer
Feeding Thickness 2~4mm
Effective width Better as your drawing or from our designer
Productivity 15/min

Crash Barrier Roll Forming Machine , Metal Roofing Roll Former With Auto Stacker

Crash Barrier Roll Forming Machine , Metal Roofing Roll Former With Auto Stacker
