30g 0.001g Check Weigher Machaine
30g 0.001g Check Weigher Machaine
Specifications
Brand Name :
innovation
Model Number :
INCW30G
Place of Origin :
China
MOQ :
1 set
Payment Terms :
T/T, Western Union
capacity :
30g
accuracy :
0.012g
speed :
10-120m/min.
Description

INCW30G 30g 0.001g 120m Per Min Check Weigher Machine

The high-precision weighing scale developed for small square or thick strip packing objects on high-speed production line can be directly installed at the lower end of the discharge port of the automatic packaging machine for on-line dynamic weighing and product weight statistics, weighing range of 0.5-30 G

Advantages:

1. The weight determination time is short and the recognition accuracy is high;

2. A variety of statistical methods: batch statistics, qualified product statistics, all statistics;

3. Modern high speed and high precision digital filtering algorithm;

4. It can store 20000 pieces of sorting (re inspection) result data, and set or export product sorting (re inspection) parameters through USB;

5. Multiple elimination methods (pneumatic lever or flat push rod) can be selected to eliminate overweight or under weight products;

30g 0.001g Check Weigher Machaine

Model no.: INCW

MODEL INCW/B201830 INCW/B201208 INCW/B201216
CAPACITY 0.5-30g
SORTING CAPACITY 300pcs/min 80pcs/min 160pcs/min
MAX. ACCURACY(±3σ) ±0.018g ±0.012g ±0.015g
RESOLUTION 0.001g
BELT SPEED 30-120m/min 10-40m/min 30-80m/min
PLATFORM SIZE LENGTH 250mm 400mm 400mm
WIDTH 100mm
PRODUCT SIZE LENGTH ≤150mm ≤250mm ≤250mm
WIDTH ≤80mm
TOTAL LENGTH 1050mm 1200mm 1200mm
QTY. TO SET PRODUCTS 100
HEIGHT OF THE PLATFORM 750±50mm
POWER SUPPLY 220VAC
AIR SUPPLY 1.0MLPa,150NL/min
WEIGHT CHECKING TYPE LEVEL
RECOMMENDED PRODUCTS Small medicine bag or bottle, thick and long medicine bag
