Tankless Cold Climate Air Source Heat Pump Air Conditioning And Hot Water Unit
Tankless Cold Climate Air Source Heat Pump Air Conditioning And Hot Water Unit
Specifications
Brand Name :
Yushen
Model Number :
9Kw, 14Kw, 18KW
Certification :
CCC, ISO, CQC
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
10 sets/day
Delivery Time :
1-2weeks
Packaging Details :
Reinforced Carton box with wooden tray
Key word :
Cold climate Air Source Heat Pump
Use :
household, hotel, apartment etc.
Tankless/tank :
Tankless
Installation :
wall or floor mouted
ambient temeprature :
-25C~+45C
Electricity :
220V-3N-50hz
Description

Air Energy Heat Pump Air Conditioning And Hot Water Unit Suitable for Cold Climate

ASHP characters

1.Work under the temperature -25°C stably with good COP, by adopting the super inverter tech Copeland compressor special designed.
2.Base frame and external panels made of galvanized powder coated steel
3.Water exchanger equipped with high efficiency tube in heat exchanger
4.High efficiency compressor with R410a refrigerant
5.Fully sealed control box with water proof level IPX4
6.Automatic defrosting function included

Parameters

code name.pdf

Model SLNA(B)-009U(P) SLNA(B)-014U(P) SLNA-018U
Compressor capacity 3HP 5HP 6HP
Function Heating and Cooling Heating and Cooling Heating and Cooling
Electricity 220V-1N-50Hz 220V-1N-50Hz 220V-1N-50Hz
Working conditions ℃ -25~～+45 -25~～+45 -25~～+45
Data Heata Nominal capacity KW 5.8 9.2 12
Input power KW 2.52 3.96 5.0
COP / 2.3 2.3 2.4
Heating IPLV(H) 2.53 2.6 2.7
Coolb Nominal capacity KW 6.5 11.0 14
Input power KW 2.6 4.31 5.6
COP / 2.5 2.55 2.5
Cooling IPLV(C) 2.7 2.75 2.7
A7W35c KW/COP 9.2/4.10 14.0/4.1 19.5/4.21
A2W35 KW/COP 8.0/3.6 11.2/3.60 16.8/3.65
A-7W35 KW/COP 5.9/2.7 9.5/3.0 12.0/3.0
A-15W55 KW/COP 5.0/1.90 8.4 /1.94 10.8 /1.94
A-20W45 KW/COP 4.5/1.95 7.7/2.00 9.2/2.02
Max. running currency A 18 30 35.6
Compressor quantity set 1 1 1
Refrigerant/charging quantity kg / R404A/2.2 R22/4.50 R22/4.80
Air blow type / Side Side Side
Water pipe diameter inch G1〞 G1.2〞 G1.2〞
Rating flow m³/h 1.6 2.5 3.2
Water side pressure loss kPa ≤35 ≤35 ≤45
Noise level dB(A) 59 61 61
Overall dimensions(L×W×H) mm 1087×435×901 1120×440×1360 1120×440×1360
Weight kg 70 130 249

a: Nominal heating conditions: ambient dry bulb temperature-12℃, wet bulb temperature-14℃, outlet water temperature 41℃, water flow 0.172 * nominal heating capacity

b:Nominal refrigeration conditions: ambient dry bulb temperature 35℃, outlet water temperature 7℃, water flow 0.172 * nominal cooling capacity

c:A7W35 working condition: inlet air temperature 7℃, outlet water temperature 35℃

Yushen Products

  • Fan of heat exchanger is big diameter Jagged type, which increase the air flow tangent length when air going through fans, reduce noise; When the air volume is increased, the heat exchanger is more evenly.
  • Multi-throttle channel design is accurate.

Multiple energy-saving devices in a single system, precise control of refrigerant flow, enabling the unit to maximize heat/cooling capacity and maximum energy efficiency in various working environments, reducing operating costs

  • The water side shell and tube heat exchanger have high efficiency and reliability.

The industry's leading refrigerant distribution technology can effectively improve the uniformity of gas-liquid two-phase fluid distribution into heat transfer tubes, improve the utilization of heat exchange tubes, and achieve efficient heat transfer.

  • Large-area hydrophilic aluminum heat exchangers increase the heat production.

The four-row tube V-shaped arrangement has high heat exchange efficiency and uniform wind speed distribution.

It adopts 9.52*0.35 internal thread high-efficiency heat exchange copper tube and 3.1mm large-format hydrophilic aluminum fins with better hydrophobicity; it improves the operating efficiency during frosting and reduces the number of defrosting.

The optimized long flow path design and wide expansion of the expansion throttle ensure uniform distribution of refrigerant in low temperature environments. Ensure even frosting, complete defrosting, strong heating and efficient operation
