380 V Air Source Heat Pump System 12.5 HP Automatically Defrosting Function
380 V Air Source Heat Pump System 12.5 HP Automatically Defrosting Function
Specifications
Brand Name :
Yushen
Model Number :
SLNB-035Y
Certification :
CCC, ISO, CQC
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
10 sets/day
Delivery Time :
1-2 weeks
Packaging Details :
Reinforced Carton box with wooden tray
Key word :
Commercial Air Source Heat Pump
Compressor capacity :
12.5HP
Function :
Heating and cooling
Air blow type :
Side
working conditions :
-25C ~+45C
Compressor quantity :
1
Description

12.5 HP Heat Pump system of Air Source For Commercial Heating and Cooling

Quick Details

  • Top Accessories: world famous brand compressor, danfoss valve, high efficiency copper-finned exchanger etc. to ensure a top quality.
  • All Weather Operation: stable operation without being influenced by weather.
    10. Refrigerant of R22,R407C,R410A are available.
  • High degree of automation, simple operation, unattended operation
  • Automatically defrosting function included.
  • It can be combined with fan coil, radiator, floor heating, etc.

Model data

Model SLNB-035Ycode name.pdf
Compressor capacity 12.5HP
Function Heating and Cooling
Electricity 380V-3N-50Hz
Working conditions ℃ -25~+45
Data Heata Nominal capacity KW 22.3
Input power KW 9.4
COP / 2.35
Heating IPLV(H) 2.7
Coolb Nominal capacity KW 28
Input power KW 10.4
COP / 2.7
Cooling IPLV(C) 2.7
A7W35c KW/COP 35.0/4.1
A2W35 KW/COP 28.5/3.60
A-7W35 KW/COP 23.5/2.9
A-15W55 KW/COP 20.2 /1.94
A-20W45 KW/COP 18.7/2.02
Max. running currency A 27
Compressor quantity set 1
Refrigerant/charging quantity kg / R22/9
Air blow type / Side
Water pipe diameter mm 32
Rating flow m³/h 5.9
Water side pressure loss kPa ≤45
Noise level dB(A) 62
Overall dimensions(L×W×H) mm 1490×900×1900
Weight kg 350

a: Nominal heating conditions: ambient dry bulb temperature-12℃, wet bulb temperature-14℃, outlet water temperature 41℃, water flow 0.172 * nominal heating capacity

b:Nominal refrigeration conditions: ambient dry bulb temperature 35℃, outlet water temperature 7℃, water flow 0.172 * nominal cooling capacity

c:A7W35 working condition: inlet air temperature 7℃, outlet water temperature 35℃

Products Advantages

  • Suitable for environmental temperature:-25℃ to +45 ℃ /-13℉ to 113 ℉
  • 35% more powerful than other products, long heating time and less defrosting time
  • Quality Components such as Copeland compressor, Danfoss valves
  • Pay attention to details such as every stainless-steel screw has cushion to prevent from water corrosion
  • Clean and clear wiring and lining
  • 100% finished products testing

Applications

Villas

office buildings

hotels and restaurants

Apartments

Delivery and Packing

Strong and safe packaging for each product so that they will not be any damaged,keeping good the unit performance to users.
