Eco Friendly Central Air Conditioner Heat Pump Single Cooling / Cold
Central Air Conditioner Heat Pump Feature:
1. Use stainless steel plate heat exchanger, ensure high efficient performance for both heating and cooling.
2. Base frame and the cabinet made of Galvanized powder coated steel or stainless steel optional.
3. Intelligent Controlling. Low noise, Automatic defrosting, Power-off Memory&Multi Self-protection
4.Connect the room linked switch to thermostat. Control heat pump work on/off according to room temperature
Central Air Conditioner Heat Pump Introduction
Model of cooling unitcode name.pdf
Model | SDLC-040Y | SDLC-063Y | |||
Compressor capacity | 15HP | 25HP | |||
Function | Cool | Cool | |||
Electricity | 380V 3N-50Hz | 380V 3N-50Hz | |||
Working conditions | ℃ | -25~+45 | -25~+45 | ||
Data | Coola | Nominal capacity | KW | 40 | 63 |
Input power | KW | 12.8 | 20.1 | ||
COP | / | 3.11 | 3.13 | ||
A35W0b | KW/COP | 30.3/2.73 | 48.58/2.79 | ||
A35W-5 | KW/COP | 25.7/2.38 | 41.26/2.51 | ||
A35W-10 | KW/COP | 21.4 /2.04 | 34.72 /2.17 | ||
A35W-15 | KW/COP | 17.3/1.69 | 29.06/1.91 | ||
Max. running currency | A | 35 | 56 | ||
Compressor quantity | Set | 2 | 2 | ||
Refrigerant/charging quantity kg | / | R22/11*2 | R22/15*2 | ||
Air blow type | / | Top | Top | ||
Water pipe diameter | mm | 50 | 50 | ||
Rating flow | m³/h | 8.3 | 12.6 | ||
Water side pressure loss | kPa | ≤45 | ≤45 | ||
Noise level | dB(A) | 62 | 62 | ||
Overall dimensions(L×W×H) | mm | 1450×1100×2080 | 2100×1100×2080 | ||
Weight | kg | 470 | 730 |
FAQ
How about your delivery time?
A: Generally, standard product will take one or two weeks after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Do I need to remove my other heat sources?
A:No an air source heat pump can run in conjunction with your other heat sources such as, wood burning stoves etc.
What kind of maintenance dose a heat pump required?
A:There is some maintenance that the owner can do themselves. It includes keeping the outdoor unit clean and free of debris. Other than this it is important to have your system serviced once a year. Project Air Source will provide details of this.
