Low Noise Central Air Conditioner Heat Pump Cooling And Heating Function
Low Noise Central Air Conditioner Heat Pump Cooling And Heating Function
Specifications
Brand Name :
Yushen
Model Number :
017Y~075Y
Certification :
CCC, ISO, CQC
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
10 sets/day
Delivery Time :
1-2weeks
Packaging Details :
Reinforced Carton box with wooden tray
Name :
Central Air Conditioner Heat Pump
Compressor capacity :
6Hp ~25HP
Function :
Cooling And Heating Function
Noise level :
62dba
Feature :
Low Noise
Electricity :
380V-3P-50hz
Working conditions :
-25C ~+45C
Description

Low Noise Central Air Conditioner Heat Pump Cooling And Heating Function

Central Air Conditioner Heat Pump Features

Central Air Conditioner Heat Pump (ASHP) is a system which transfers heat from outside to inside a building, or vice versa. Under the principles of vapor compression refrigeration, an ASHP uses a refrigerant system involving a compressor and a condenser to absorb heat at one place and release it at another. They can be used as a space heater or cooler, and are sometimes called "reverse-cycle air conditioners".

In domestic heating use, an ASHP absorbs heat from outside air and releases it inside the building, as hot air, hot water-filled radiators, underfloor heating and/or domestic hot water supply. The same system can often do the reverse in summer, cooling the inside of the house. When correctly specified, an ASHP can offer a full central heating solution and domestic hot water

Central Air Conditioner Heat Pump Parameter

A7W35 working condition: inlet air temperature 7℃, outlet water temperature 35℃

a: Nominal heating conditions: ambient dry bulb temperature-12℃, wet bulb temperature-14℃, outlet water temperature 41℃, water flow 0.172 * nominal

Model SLNA-032Y SLNB-047Y SLNC-075Y
Compressor capacity 10HP 15HP 25HP
Function Heating and Cooling Heating and Cooling Heating and Cooling
Electricity 380V-3N-50Hz 380V-3N-50Hz 380V-3N-50Hz
Working conditions ℃ -25~+45 -25~+45 -25~+45
Data Heata Nominal capacity KW 21.5 28.1 44.5
Input power KW 9.1 11.7 18.3
COP / 2.3 2.4 2.4
Heating IPLV(H) 2.7 2.7 2.7
Coolb Nominal capacity KW 25 39 62
Input power KW 10 13.1 20.7
COP / 2.5 2.9 3
Cooling IPLV(C) 2.7 2.7 2.7
A7W35c KW/COP 32.0/4.1 47.0/4.1 75.0/4.2
A2W35 KW/COP 27/3.60 39.5/3.20 62.5/3.20
A-7W35 KW/COP 21.5/2.8 32/2.9 50/2.9
A-15W55 KW/COP 19.7 /1.94 28.1/1.94 45.5 /1.97
A-20W45 KW/COP 18.1/2.02 23.6/2.03 37.4/2.04
Max. running currency A 25 35 56
Compressor quantity set 2 2 2
Refrigerant/charging quantity kg / R22/3.7*2 R22/10 R22/15*2
Air blow type / Top Top Top
Water pipe diameter mm 32 50 50
Rating flow m³/h 5.5 8.3 12.6
Water side pressure loss kPa ≤45 ≤45 ≤45
Noise level dB(A) 62 62 62
Overall dimensions(L×W×H) mm 1530×750×1370 1450×1100×2080 2100×1100×2080
Weight kg 320 470 730

Our service

  • Central control system, automatic and easy operation
  • Inquiry reply within 24hours
  • fast delivery 1-2 weeks
