Galanvized Steel Central Air Source Heat Pump For Hotel , School , Home
Galanvized Steel Central Air Source Heat Pump For Hotel , School , Home
Specifications
Brand Name :
Yushen
Model Number :
SDNA-075Y
Certification :
CCC, ISO, CQC
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
10 sets/day
Delivery Time :
1-2 weeks
Packaging Details :
Reinforced Carton box with wooden tray
Name :
Central Air Source Heat Pump
Compressor capacity :
25HP
Function :
Heating
Material :
Stainless Steel
Weight :
730Kg
Application :
Hotel , School , Home
Description

Galvanized Steel Central Air Source Heat Pump For Hotel , School , Home

Central Air Source Heat Pump Benifits

  • Economical Operation: generally cost less to operate than other types of conventional heating systems, save your electricity or gas bills
  • Easy Operation: With intelligent control systems which convenient and simple operation
  • Safety: Operate at a high efficiency with no flames,fumes,or flues;Water and electricity isolated
  • no fuel deliveries needed
  • can heat your home as well as your water
  • minimal maintenance required
  • can be easier to install than a ground source heat pump
  • Unlike gas and oil boilers, heat pumps deliver heat at lower temperatures over much longer periods.

Central Air Source Heat Pump Applications

  • Cooling for any indoor air conditioning conditions such as office building, hotel, school, home.
  • Produce cool water for factory use

Central Air Source Heat Pump Parameters

Model SDNA-075Ycode name.pdf
Compressor capacity 25HP
Function Heat
Electricity 380V 3N-50Hz
Working conditions ℃ -25~+45
Data Heata Nominal capacity KW 44.5
Input power KW 18.3
COP / 2.4
Heating IPLV(H) 2.7
A7W35c KW/COP 75.0/4.2
A2W35 KW/COP 62.5/3.20
A-7W35 KW/COP 52.5/3.0
A-15W55 KW/COP 45.5 /1.97
A-20W45 KW/COP 37.4/2.04
Max. running currency A 56
Compressor quantity set 2
Refrigerant/charging quantity kg / R22/10*2
Air blow type / Top
Water pipe diameter mm 50
Rating flow m³/h 12.6
Water side pressure loss kPa ≤45
Noise level dB(A) 62
Overall dimensions(L×W×H) mm 2100×1100×2080
Weight kg 730

a: Nominal heating conditions: ambient dry bulb temperature-12℃, wet bulb temperature-14℃, outlet water temperature 41℃, water flow 0.172 * nominal

b:Nominal refrigeration conditions: ambient dry bulb temperature 35℃, outlet water temperature 7℃, water flow 0.172 * nominal cooling capacity

c:A7W35 working condition: inlet air temperature 7℃, outlet water temperature 35℃

Company History

Yushen Engergy was known as Shandong Aoxin Heat Pump&Air Conditioning Co., Ltd. Before, It adopted the advantaged production lines and technologies, implementing 100% finished products testing.

In the past four years, its products have been used in Hebei, Shandong, Shanxi, Gansu, Ningxia, Inner Mongolia, Xinjiang, and Dalian provinces and products performance are tested by the market. Its ultra-low-temperature heat pumps could provide heating source even in -25℃ with a high COP, which are proved by the increasing project cases in Inner Mongolia provinces( N 40°).
