High Power Central Air Source Heat Pump For Home Cooling And Heating
High Power Central Air Source Heat Pump For Home Cooling And Heating
Specifications
Brand Name :
Yushen
Model Number :
SLNC-075Y
Certification :
CCC, ISO, CQC
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
10 sets/day
Delivery Time :
1-2weeks
Packaging Details :
Reinforced Carton box with wooden tray
Name :
Central Air Source Heat Pump
Compressor capacity :
25HP
Electricity :
380V-3N-50Hz
Working conditions :
-25~+45
Overall size :
2100×1100×2080mm
Weight :
Office Building Cooling & Heating
Description

High Power Central Air Source Heat Pump For Home Cooling And Heating

More about entral Air Source Heat Pump

  • Green and environmental protection: The air source heat pump absorbs heat from the natural air of the surrounding environment and has little impact on the environment. It is a true environmental protection equipment.
  • Safe and comfortable: the water tank and the main unit are completely separated and have reliable safety. A variety of terminal options for customers to enjoy
  • Easy to install: the unit can be installed outdoors, such as in open spaces such as roofs and floors. It has a small footprint and is easy to install. It does not need to set up a machine room to save space.

entral Air Source Heat Pump Application:

It is suitable for the cooling &heating of office building, villa, hotel and community. In summer, it provide water of 7℃ for cooling; in winter it provide water of 50℃

Central Air Source Heat Pump features:

1. 40% energy-saving than AC in heating

2. Water circulation in the enders, safe and comfortable

3. High automation, easy operation

4. It could be connected with different enders, e.g. fan coil,radiator,floor heating , convenient and high-efficient

Central Air Source Heat Pump Parameter

Model SLNC-075Ycode name.pdf
Compressor capacity 25HP
Function Heating and Cooling
Electricity 380V-3N-50Hz
Working conditions ℃ -25~+45
Data Heata Nominal capacity KW 44.5
Input power KW 18.3
COP / 2.4
Heating IPLV(H) 2.7
Coolb Nominal capacity KW 62
Input power KW 20.7
COP / 3
Cooling IPLV(C) 2.7
A7W35c KW/COP 75.0/4.2
A2W35 KW/COP 62.5/3.20
A-7W35 KW/COP 50/2.9
A-15W55 KW/COP 45.5 /1.97
A-20W45 KW/COP 37.4/2.04
Max. running currency A 56
Compressor quantity set 2
Refrigerant/charging quantity kg / R22/15*2
Air blow type / Top
Water pipe diameter mm 50
Rating flow m³/h 12.6
Water side pressure loss kPa ≤45
Noise level dB(A) 62
Overall dimensions(L×W×H) mm 2100×1100×2080
Weight kg 730

A7W35 working condition: inlet air temperature 7℃, outlet water temperature 35℃

a: Nominal heating conditions: ambient dry bulb temperature-12℃, wet bulb temperature-14℃, outlet water temperature 41℃, water flow 0.172 * nominal

Our service

  • Engineer design drawing
  • Central control system, automatic and easy operation
  • Inquiry reply within 24hours
  • fast delivery 1-2 weeks
