Heating Commercial Air Source Heat Pump For Hotels And Restaurants 730Kg
Heating Commercial Air Source Heat Pump For Hotels And Restaurants 730Kg
Specifications
Brand Name :
Yushen
Model Number :
Commercial Air Source Heat Pump
Certification :
CCC, ISO, CQC
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
10 sets/day
Delivery Time :
1-2 weeks
Packaging Details :
Reinforced Carton box with wooden tray
Key word :
Commercial Air Source Heat Pump
Compressor capacity :
25HP
Function :
Heating
Size :
2100×1100×2080mm
Weight :
730Kg
Application :
Hotels And Restaurants
Description

Heating Commercial Air Source Heat Pump For Hotels And Restaurants 730Kg

Commercial Air Source Heat Pump Quick Details

  • Commercial Air Source Heat Pump is the best substitute for coal boiler, heater 40% energy-saving than air conditioner, use less than 1/3 electricity that of electricity heating.
  • Best choice for office building 's energy management
  • High automation, easy operation
  • Commercial Air Source Heat Pump could be connected with different enders, e.g. fan coil, radiator, floor heating, convenient and high-efficient

Model data

Model SDNA-075Ycode name.pdf
Compressor capacity 25HP
Function Heat
Electricity 380V 3N-50Hz
Working conditions ℃ -25~+45
Data Heata Nominal capacity KW 44.5
Input power KW 18.3
COP / 2.4
Heating IPLV(H) 2.7
A7W35c KW/COP 75.0/4.2
A2W35 KW/COP 62.5/3.20
A-7W35 KW/COP 52.5/3.0
A-15W55 KW/COP 45.5 /1.97
A-20W45 KW/COP 37.4/2.04
Max. running currency A 56
Compressor quantity set 2
Refrigerant/charging quantity kg / R22/10*2
Air blow type / Top
Water pipe diameter mm 50
Rating flow m³/h 12.6
Water side pressure loss kPa ≤45
Noise level dB(A) 62
Overall dimensions(L×W×H) mm 2100×1100×2080
Weight kg 730

a: Nominal heating conditions: ambient dry bulb temperature-12℃, wet bulb temperature-14℃, outlet water temperature 41℃, water flow 0.172 * nominal

b:Nominal refrigeration conditions: ambient dry bulb temperature 35℃, outlet water temperature 7℃, water flow 0.172 * nominal cooling capacity

c:A7W35 working condition: inlet air temperature 7℃, outlet water temperature 35℃

Commercial Air Source Heat Pump Advantages

  • Suitable for environmental temperature:-25℃ to +45 ℃ /-13℉ to 113 ℉
  • 35% more powerful than other products, long heating time and less defrosting time
  • Quality Components such as Copeland compressor, Danfoss valves
  • Pay attention to details such as every stainless-steel screw has cushion to prevent from water corrosion
  • Clean and clear wiring and lining
  • 100% finished products testing

Commercial Air Source Heat Pump Applications

It is suitable for the heating of

office building

hotel and community.

In winter it provide water of 50℃ for heating.
