Silent Central Heating And Cooling System / High Speed Heat Pump Central Heating
Silent Central Heating And Cooling System / High Speed Heat Pump Central Heating
Specifications
Brand Name :
Yushen
Model Number :
SLNC-075Y
Certification :
CCC, ISO, CQC
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
10 sets/day
Delivery Time :
1-2weeks
Packaging Details :
Reinforced Carton box with wooden tray
key word :
Central Heating And Cooling System
Compressor capacity :
25HP
Service area :
800~1000 sqm per set
Function :
cooling and heating
Overall size :
2100×1100×2080mm
Advantage :
High Speed
Description

Silent Central Heating And Cooling System / High Speed Heat Pump Central Heating

Central Heating And Cooling System DESCRIPTION

Central Heating And Cooling System use electricity to capture heat and move it from one place to another. They don't generate heat.

Higher efficiency heat pump pool heaters usually use scroll compressors versus the reciprocal compressors of standard units.

Heat pump pool heaters work efficiently as long as the outside temperature remains above the 45ºF–50ºF range. The cooler the outside air they draw in, the more energy they use. However, since most people use outdoor swimming pools during warm and mild weather, this usually isn't an issue.

Heat Pump Cooling System Parameter

Model SLNC-075Ycode name.pdf Central Heating And Cooling System
Compressor capacity 25HP
Function Heating and Cooling
Electricity 380V-3N-50Hz
Working conditions ℃ -25~+45
Data Heata Nominal capacity KW 44.5
Input power KW 18.3
COP / 2.4
Heating IPLV(H) 2.7
Coolb Nominal capacity KW 62
Input power KW 20.7
COP / 3
Cooling IPLV(C) 2.7
A7W35c KW/COP 75.0/4.2
A2W35 KW/COP 62.5/3.20
A-7W35 KW/COP 50/2.9
A-15W55 KW/COP 45.5 /1.97
A-20W45 KW/COP 37.4/2.04
Max. running currency A 56
Compressor quantity set 2
Refrigerant/charging quantity kg / R22/15*2
Air blow type / Top
Water pipe diameter mm 50
Rating flow m³/h 12.6
Water side pressure loss kPa ≤45
Noise level dB(A) 62
Overall dimensions(L×W×H) mm 2100×1100×2080
Weight kg 730

A7W35 working condition: inlet air temperature 7℃, outlet water temperature 35℃

a: Nominal heating conditions: ambient dry bulb temperature-12℃, wet bulb temperature-14℃, outlet water temperature 41℃, water flow 0.172 * nominal

Central Heating And Cooling System Advantages

  • Larger application range , yushen heat pump could be used from environmental temperature:-25℃ to +45 ℃ /or from -13℉ to 113 ℉
  • 100% finished products testing,quality Components such as Copeland compressor, Danfoss valves
  • 35% more powerful than other products,yushen air-source heat pump has longer heating time and shorter defrosting time
Product tags

heat pump heating system

,

forced air heating unit

,

heat pump central heating
