Heating And Cooling Heat Pump Heating And Cooling System For Home Use
Heating And Cooling Heat Pump Heating And Cooling System For Home Use
Specifications
Brand Name :
Yushen
Model Number :
SLNC-075Y
Certification :
CCC, ISO, CQC
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
10 sets/day
Delivery Time :
1-2weeks
Packaging Details :
Reinforced Carton box with wooden tray
Key word: :
Greenhouse Air Source heat pump
Compressor capacity :
25P
Function :
Heating and Cooling
Compressor type :
Copeland Scroll compressor
Working temeprature :
-25C ~+45C
Noise :
62DBA
Description

Heating And Cooling Heat Pump Heating And Cooling System For Home Use

Project Introduction

Location: Heibei province

Greenhouse area: 2000 sqm

Function: In summer cooling; in winter heating supplement for solar energy greenhouse.

Project function: Ecological agriculture sightseeing greenhouse

Advantages: Energy saving, zero pollution, solve low temeprature problem of greenhouse in winter

Yushen Heat Pump Features

  • Yushen Air-source heat pump Cooling equipment could work in envirronment from -25C to +45C
  • Yushen air-source Cooling equipment is 40% energy-saving than that of AC unit in general .
  • It is water circulation in the enders, safe and comfortable
  • With full protection functions including water flow, high/low pressure, phase order, over-current ect.
  • Galvanized steel cabinet with powder painting in grey or black, strong and durable.
  • different enders, suitable e.g. fan coil,radiator,floor heating , convenient and high-efficient

Technical data

Compressor brand: Copeland

Water side heat exchanger: shell and tube type

Air side heat exchanegr: inner thread copper tube and Hydrophilic aluminum foils

Model SLNC-075Y
Compressor capacity 25HP
Function Heating and Cooling
Electricity 380V-3N-50Hz
Working conditions ℃ -25~+45
Data Heata Nominal capacity KW 44.5
Input power KW 18.3
COP / 2.4
Heating IPLV(H) 2.7
Coolb Nominal capacity KW 62
Input power KW 20.7
COP / 3
Cooling IPLV(C) 2.7
A7W35c KW/COP 75.0/4.2
A2W35 KW/COP 62.5/3.20
A-7W35 KW/COP 50/2.9
A-15W55 KW/COP 45.5 /1.97
A-20W45 KW/COP 37.4/2.04
Max. running currency A 56
Compressor quantity set 2
Refrigerant/charging quantity kg / R22/15*2
Air blow type / Top
Water pipe diameter mm 50
Rating flow m³/h 12.6
Water side pressure loss kPa ≤45
Noise level dB(A) 62
Overall dimensions(L×W×H) mm 2100×1100×2080
Weight kg 730

Tested conditions:

a:Nominal Cooling conditions: ambient dry bulb temperature35℃, , outlet water temperature 7℃, water flow 0.172 * nominal cooling capacity

b:A7W35 working condition: inlet air temperature 7℃, outlet water temperature 35℃

Other applications

Air source heat pump could aslo work as the outdoor unit for Air conditioning of,

  • office building
  • swiming pool
  • villa
  • House
  • hotel
  • Residential community central heating
  • Market/shopping mall

Product Certificates

Heating And Cooling Heat Pump Heating And Cooling System For Home Use
