Energy Saving High Temperature Air Source Heat Pumps Copeland Compressor
Energy Saving High Temperature Air Source Heat Pumps Copeland Compressor
Specifications
Brand Name :
Yushen
Model Number :
SDWA-014/017/034/075YB
Certification :
CCC, ISO, CQC
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
10 sets/day
Delivery Time :
1-2weeks
Packaging Details :
Reinforced Carton box with wooden tray
Name :
High Temperature Air Source Heat Pumps
Compressor capacity :
75KW
Refrigerant :
R22/R407C/R134A/ R410A
Compressor brand :
Copeland
Feature :
Energy Saving
Air blow type :
top
Description

Energy Saving High Temperature Air Source Heat Pumps Copeland Compressor​

High Temperature Air Source Heat Pumps Features

This series is splendid for heating and cooling, which are suitable for office builing, hotels, factories, schools, salons , leisure centers and other commercial places..

Yushen High Temperature Air Source Heat Pumps advantages

1. Jet boosting technology, the heat of -25 °C is not attenuated, and the cooling capacity of 43 °C is not attenuated.
2. Intelligent defrosting, frost defrosting, no frost heating, maximizing heating energy efficiency.
3. Environmentally friendly refrigerant, does not destroy the ozone layer;
4. Energy saving 35% compared with similar products

High Temperature Air Source Heat Pumps Model data

Model SDWA-017Y SDWA-034YB SDWA-075YB
Compressor capacity 6HP 10HP 25HP
Function Heat Heat Heat
Electricity 380V 3N-50Hz 380V 3N-50Hz 380V 3N-50Hz
Working conditions ℃ -25~+43 -25~+43 -25~+43
Nominal heating capacity KW 17 34 75
COP KW/KW 4.1 4 4
Nominal input power KW 4.14 8.25 20.5
Max. running currency A 11.5 23 60
Highest water temperature ℃ 60 60 60
Compressor quantity Set 1 2 2
Refrigerant/charging quantity kg / R22/4.8 R22/3.7*2 R22/10*2
Air blow type / Top Top Top
Water pipe diameter / 1 1/2'' 1 1/2'' 50
Rating flow m³/h 3 6 12
Water side pressure loss kPa ≤45 ≤45 ≤45
Noise level dB(A) 62 62 62
Overall dimensions(L×W×H) mm 860×820×1080 1530×750×1370 2100×1100×2080
Weight kg 197 320 830
Nominal heating conditions:ambient dry bulb temperature 7℃, web bulb temperature 6℃, water inlet temperature 9℃,water outlet temperature 55℃

Comparasion to solar heater

1. Wide application range, the product temperature range is -10-40 °C, and it is used all the year round. It can be used normally without the bad weather such as overcast, rain, snow and winter night.

2, continuous heating, compared with the traditional solar water storage type, the heat pump can be continuously heated, continuous hot water supply to meet user needs.

3. Low operating cost: Compared with conventional solar energy, when the sun is good in spring, summer and autumn, the running cost is higher than that of solar energy, but in rainy days and nights, the thermal efficiency is much higher than that of solar energy. On average, the annual energy consumption of conventional solar-assisted systems is much higher than the total energy consumption of heat pumps throughout the year.

4, easy to install: air source heat pump occupies a small space, the shape is similar to the air conditioner outdoor unit, can be directly connected to the insulation tank or connected to the heating pipe network, suitable for high-rise buildings in large and medium-sized cities, for large central heating problems, heat pumps Is the best choice.
