Office Building Air Source Heat Pump Air Conditioning / Electric Air To Air Heat Pump
Office Building Air Source Heat Pump Air Conditioning / Electric Air To Air Heat Pump
Specifications
Brand Name :
Yushen
Model Number :
SDNA-075Y, SDNA-090YB
Certification :
CCC, ISO, CQC
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
10 sets/day
Delivery Time :
1-2 weeks
Packaging Details :
Reinforced Carton box with wooden tray
Key word :
Air Source Heat Pump Air Conditioning
Compressor capacity :
6HP to 25HP per set
Function :
Heating and cooling
Application :
Office Building
water flow :
3.2M3/h to 12M3/h
Refrigerant :
R134a/R410a/R404a
Description

Office Building Air Source Heat Pump Air Conditioning / Electric Air To Air Heat Pump

Air Source Heat Pump Air Conditioning Application

Air Source Heat Pump Air Conditioning provide house heating and hot water,where hot water needed,it is more energy saving than other equipments,it is widely use in hospital,sauna,factory,commercial centre,slaughter.

Air Source Heat Pump Air Conditioning Characters

1. One unit could both heating in winter and cooling in summer

2. Multiple units could connected to a station, control inside rooms are independent

3. It is 40% energy saving than convnetional Air conditioner outdoor unit in heating.

4. Safety. There is no electric heating equipment in the air source hot water tank. When the air source is continuously transmitted to the hot water tank during operation, there is absolutely no leakage, electric shock, explosion or poisoning.
5.Comfortable. The water system has high stability and can maintain a constant indoor temperature. In addition, the heating and cooling methods are closer to the human body's temperature, which makes the refrigeration and heating more comfortable and does not give the user a feeling of chilling and hot.

Heating model code name.pdf

Model SLNA-032Y SLNB-035Y SLNB-047Y SLNC-075Y
Compressor capacity 10HP 12.5HP 15HP 25HP
Function Heating and Cooling Heating and Cooling Heating and Cooling Heating and Cooling
Electricity 380V-3N-50Hz 380V-3N-50Hz 380V-3N-50Hz 380V-3N-50Hz
Working conditions ℃ -25~+45 -25~+45 -25~+45 -25~+45
Data Heata Nominal capacity KW 21.5 22.3 28.1 44.5
Input power KW 9.1 9.4 11.7 18.3
COP / 2.3 2.35 2.4 2.4
Heating IPLV(H) 2.7 2.7 2.7 2.7
Coolb Nominal capacity KW 25 28 39 62
Input power KW 10 10.4 13.1 20.7
COP / 2.5 2.7 2.9 3
Cooling IPLV(C) 2.7 2.7 2.7 2.7
A7W35c KW/COP 32.0/4.1 35.0/4.1 47.0/4.1 75.0/4.2
A2W35 KW/COP 27/3.60 28.5/3.60 39.5/3.20 62.5/3.20
A-7W35 KW/COP 21.5/2.8 23.5/2.9 32/2.9 50/2.9
A-15W55 KW/COP 19.7 /1.94 20.2 /1.94 28.1/1.94 45.5 /1.97
A-20W45 KW/COP 18.1/2.02 18.7/2.02 23.6/2.03 37.4/2.04
Max. running currency A 25 27 35 56
Compressor quantity set 2 1 2 2
Refrigerant/charging quantity kg / R22/3.7*2 R22/9 R22/10 R22/15*2
Air blow type / Top Side Top Top
Water pipe diameter mm 32 32 50 50
Rating flow m³/h 5.5 5.9 8.3 12.6
Water side pressure loss kPa ≤45 ≤45 ≤45 ≤45
Noise level dB(A) 62 62 62 62
Overall dimensions(L×W×H) mm 1530×750×1370 1490×900×1900 1450×1100×2080 2100×1100×2080
Weight kg 320 350 470 730

Yushen Air Source Heat Pump Air Conditioning

  • It could work in extreme environment /Suitable for environmental temperature:-25℃ to +45 ℃ /-13℉ to 113 ℉
  • Yushen air source heat pump is 35% more powerful than other products, long heating time and less defrosting time
  • No capacity decay under low temperature, keep high COP in winter
  • Quality Components such as Copeland compressor, Danfoss valves
  • Pay attention to details such as every stainless-steel screw has cushion to prevent from water corrosion
  • Clean and clear wiring and lining
  • 100% finished products testing
  • Having only one unit which could both heat and cool to maintain means lower repair costs and less work in general.
