High COP Commercial Air Source Heat Pump With Special Pump 12.5 HP Compressor
High COP Commercial Air Source Heat Pump With Special Pump 12.5 HP Compressor
Specifications
Brand Name :
Yushen
Model Number :
Commercial Air Source Heat Pump
Certification :
CCC, ISO, CQC
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
10 sets/day
Delivery Time :
1-2 weeks
Packaging Details :
Reinforced Carton box with wooden tray
Key word :
Commercial Air Source Heat Pump
Compressor capacity :
12.5HP
Advantage :
Energy Saving
Air blow type :
Side
working conditions :
-25C ~+45C
Compressor quantity :
1
Description

High COP Commercial Air Source Heat Pump With Special Pump 12.5 HP Compressor

Commercial Air Source Heat Pump Brief Introduction

Unit features:
1, efficient
◆ The unit adopts a special pump for heat pump type, which matches the high-efficiency condenser with the evaporator and the inlet expansion valve. The four components are perfectly matched.
2, reliable operation
◆ The unit has 7 kinds of safety protection measures to ensure the normal operation of the unit.
◆ The unit is designed for double circuit and double compressor. When a single compressor fails, the other compressor can still operate normally without affecting the customer's use.
◆ All units are tested by the national safety inspection system before leaving the factory to ensure that the unit performance meets national standards.

Commercial Air Source Heat Pump features:

1. 40% energy-saving than AC in heating

2 Water circulation in the enders, safe and comfortable

3. High automation, easy operation

4. It could be connected with different enders, e.g. fan coil,radiator,floor heating , convenient and high-efficient

Commercial Air Source Heat Pump Model data

Model SLNB-035Y
Compressor capacity 12.5HP
Function Heating and Cooling
Electricity 380V-3N-50Hz
Working conditions ℃ -25~+45
Data Heata Nominal capacity KW 22.3
Input power KW 9.4
COP / 2.35
Heating IPLV(H) 2.7
Coolb Nominal capacity KW 28
Input power KW 10.4
COP / 2.7
Cooling IPLV(C) 2.7
A7W35c KW/COP 35.0/4.1
A2W35 KW/COP 28.5/3.60
A-7W35 KW/COP 23.5/2.9
A-15W55 KW/COP 20.2 /1.94
A-20W45 KW/COP 18.7/2.02
Max. running currency A 27
Compressor quantity set 1
Refrigerant/charging quantity kg / R22/9
Air blow type / Side
Water pipe diameter mm 32
Rating flow m³/h 5.9
Water side pressure loss kPa ≤45
Noise level dB(A) 62
Overall dimensions(L×W×H) mm 1490×900×1900
Weight kg 350

a: Nominal heating conditions: ambient dry bulb temperature-12℃, wet bulb temperature-14℃, outlet water temperature 41℃, water flow 0.172 * nominal heating capacity

b:Nominal refrigeration conditions: ambient dry bulb temperature 35℃, outlet water temperature 7℃, water flow 0.172 * nominal cooling capacity

c:A7W35 working condition: inlet air temperature 7℃, outlet water temperature 35℃

Commercial Air Source Heat Pump Applications

Villas

office buildings

Delivery and Packing

Strong and safe packaging for each product so that they will not be any damaged,keeping good the unit performance to users.
