High Efficiency Air To Air Heat Pumps In Cold Climates , Air Source Heat Pump Cooling
High Efficiency Air To Air Heat Pumps In Cold Climates , Air Source Heat Pump Cooling
Specifications
Brand Name :
Yushen
Model Number :
SLNA-017Y/032Y/035Y/047Y/C-075Y
Certification :
CCC, ISO, Energy Concervation Product
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
10 sets/day
Delivery Time :
1-2 weeks
Packaging Details :
Reinforced Carton box with wooden tray
Name :
Air To Air Heat Pumps In Cold Climates
Compressor brand :
Copeland
Compressor capacity :
25HP
Function :
heating and cooling
Feature :
High Efficiency
Data testing conditions :
inlet air 7C , outlet water 35C
Description

High Efficiency Air To Air Heat Pumps In Cold Climates , Air Source Heat Pump Cooling

Air To Air Heat Pumps In Cold Climates DESCRIPTION

Central Heating And Cooling System use electricity to capture heat and move it from one place to another. They don't generate heat.

Higher efficiency heat pump pool heaters usually use scroll compressors versus the reciprocal compressors of standard units.

Air To Air Heat Pumps In Cold Climates Applications

Heating and cooling for all kinds of buildings such as office building, hotel and residential community.

It could connected with all kinds of indoor deveices, fan coil, radiators, floor coils.

This series standard models

Model SLNA-017Y SLNA-032Y SLNB-035Y SLNB-047Y
Compressor capacity 6HP 10HP 12.5HP 15HP
Function Heating and Cooling Heating and Cooling Heating and Cooling Heating and Cooling
Electricity 380V-3N-50Hz 380V-3N-50Hz 380V-3N-50Hz 380V-3N-50Hz
Working conditions ℃ -25~～+45 -25~+45 -25~+45 -25~+45
Data Heata Nominal capacity KW 12 21.5 22.3 28.1
Input power KW 4.55 9.1 9.4 11.7
COP / 2.4 2.3 2.35 2.4
Heating IPLV(H) 2.7 2.7 2.7 2.7
Coolb Nominal capacity KW 14 25 28 39
Input power KW 5 10 10.4 13.1
COP / 2.5 2.5 2.7 2.9
Cooling IPLV(C) 2.7 2.7 2.7 2.7
A7W35c KW/COP 19.5/4.21 32.0/4.1 35.0/4.1 47.0/4.1
A2W35 KW/COP 27/3.60 27/3.60 28.5/3.60 39.5/3.20
A-7W35 KW/COP 21.5/2.8 21.5/2.8 23.5/2.9 32/2.9
A-15W55 KW/COP 19.7 /1.94 19.7 /1.94 20.2 /1.94 28.1/1.94
A-20W45 KW/COP 18.1/2.02 18.1/2.02 18.7/2.02 23.6/2.03
Max. running currency A 25 25 27 35
Compressor quantity set 2 2 1 2
Refrigerant/charging quantity kg / R22/4.8 R22/3.7*2 R22/9 R22/10
Air blow type / Side Top Side Top
Water pipe diameter mm G1.2〞 32 32 50
Rating flow m³/h 3.2 5.5 5.9 8.3
Water side pressure loss kPa ≤45 ≤45 ≤45 ≤45
Noise level dB(A) 62 62 62 62
Overall dimensions(L×W×H) mm 1120×440×1360 1530×750×1370 1490×900×1900 1450×1100×2080
Weight kg 130 320 350 470
a:Nominal heating conditions: ambient dry bulb temperature-12℃, wet bulb temperature-14℃, outlet water temperature 41℃, water flow 0.172 * nominal heating capacity.
b:Nominal refrigeration conditions: ambient dry bulb temperature 35℃, outlet water temperature 7℃, water flow 0.172 * nominal cooling capacity
c:A7W35 working condition: inlet air temperature 7℃, outlet water temperature 35℃

About US

Shandong Yushen Energy Technology Co., Ltd.

Shandong Yushen Energy Technology Co., Ltd. established in 2014 with a registered capital of 50.2 million RMB, is a factory specialized in research & development, design, production, sales and service of air-source heat pumps drive by its mission” Leave a clean world for the future”

We have 53,000 square meter production area, 100 skilled staff members, 4 production lines with automation testing platforms. Our main products include air-source heat pump for heating, heating unit and cooling unit, hot water unit, drying units and the related supporting electrical control systems.
