High COP Operation Central Air Source Heat Pump For Hot Water Only 6~25HP
High COP Operation Central Air Source Heat Pump For Hot Water Only 6~25HP
Specifications
Brand Name :
Yushen
Model Number :
SDWA-017/034/075YB
Certification :
CCC, ISO, CQC
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
10 sets/day
Delivery Time :
1-2weeks
Packaging Details :
Reinforced Carton box with wooden tray
Name :
Central Air Source Heat Pump
Compressor capacity :
6~25HP
Refrigerant :
R410A/R22/R407C/R134A/ R410A
COP :
4.1
Operation :
High COP Operation
electricity :
380V-3P-50hz
Description

High COP Operation Central Air Source Heat Pump For Hot Water Only 6~25HP

Central Air Source Heat Pump Features
  • Fully automatic intelligent control, no need for special management.
  • The main components are all internationally renowned brand components, and the operation is more stable;
  • Efficient, high COP operation in extreme environments, heating is not attenuated

Central Air Source Heat Pump Applicable places


factories, restaurants, schools, sauna centers, beauty salons, swimming pools, greenhouses, food factories, laundries, industrial hot water and other places.

Central Air Source Heat Pump Parameters code name.pdf

Model SDWA-034YB SDWA-075YB
Compressor capacity 10HP 25HP
Function Heat Heat
Electricity 380V 3N-50Hz 380V 3N-50Hz
Working conditions ℃ -25~+43 -25~+43
Nominal heating capacity KW 34 75
COP KW/KW 4 4
Nominal input power KW 8.25 20.5
Max. running currency A 23 60
Highest water temperature ℃ 60 60
Compressor quantity Set 2 2
Refrigerant/charging quantity kg / R22/3.7*2 R22/10*2
Air blow type / Top Top
Water pipe diameter / 1 1/2'' 50
Rating flow m³/h 6 12
Water side pressure loss kPa ≤45 ≤45
Noise level dB(A) 62 62
Overall dimensions(L×W×H) mm 1530×750×1370 2100×1100×2080
Weight kg 320 830

FAQ

Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral cartons with plywood tray. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.

Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF.

Q4. How about your delivery time?
A: Generally, standard product will take one or two weeks after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
