Residential Indoor Air Source Heat Pump / Heat Pump Heating And Cooling System
Residential Indoor Air Source Heat Pump / Heat Pump Heating And Cooling System
Specifications
Brand Name :
Yushen
Model Number :
SLNA-009U(P)
Certification :
CCC, ISO, CQC
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
10 sets/day
Delivery Time :
1-2weeks
Packaging Details :
Reinforced Carton box with wooden tray
Name :
Indoor Air Source Heat Pump
Compressor capacity :
3HP
Application :
Residential
Air blow type :
Side
Suitable working conditions :
-25C~+45C
Other name :
Heat Pump Heating And Cooling System
Description

Residential Indoor Air Source Heat Pump / Heat Pump Heating And Cooling System

Indoor Air Source Heat Pump features:

1. 40% energy-saving than AC in heating

2. High automation, easy operation

3. It could be connected with different enders, e.g. fan coil,radiator,floor heating , convenient and high-efficient

Indoor Air Source Heat Pump Parameter

a: Nominal heating conditions: ambient dry bulb temperature-12℃, wet bulb temperature-14℃, outlet water temperature 41℃, water flow 0.172 * nominal heating capacity

b:Nominal refrigeration conditions: ambient dry bulb temperature 35℃, outlet water temperature 7℃, water flow 0.172 * nominal cooling capacity

c:A7W35 working condition: inlet air temperature 7℃, outlet water temperature 35℃

Model SLNA(B)-009U(P)code name.pdf
Compressor capacity 3HP
Function Heating and Cooling
Data Heata Nominal capacity KW 5.8
Input power KW 2.52
COP / 2.3
Heating IPLV(H) 2.53
Coolb Nominal capacity KW 6.5
Input power KW 2.6
COP / 2.5
Cooling IPLV(C) 2.7
A7W35c KW/COP 9.2/4.10
A2W35 KW/COP 8.0/3.6
A-7W35 KW/COP 5.9/2.7
A-15W55 KW/COP 5.0/1.90
A-20W45 KW/COP 4.5/1.95
Max. running currency A 18
Compressor quantity set 1
Refrigerant/charging quantity kg / R404A/2.2
Air blow type / Side
Water pipe diameter inch G1〞
Rating flow m³/h 1.6
Water side pressure loss kPa ≤35
Noise level dB(A) 59
Overall dimensions(L×W×H) mm 1087×435×901
Weight kg 70

Indoor Air Source Heat Pump Advantages

1. Yushen ASHP could work in untra low temeprature cold climate -25C

2. Jet Booster compressor No decay in heating in low environmental temperature

3. long heating time and less defrosting time,35% more powerful than other products
