50 - 200mm Thickness Pu Sandwich Panel Cold Storage Chamber Flame Resistance
50 - 200mm Thickness Pu Sandwich Panel Cold Storage Chamber Flame Resistance
Specifications
Brand Name :
Green&Health
Model Number :
PU Sandwich Coldroom Panel
Certification :
CE CCC
Place of Origin :
GuangZhou
MOQ :
One Piece
Payment Terms :
T/T
Supply Ability :
200 pieces / month
Delivery Time :
15 ~ 20 work days
Packaging Details :
Wood Packaging
Type :
Polyurethane Sandwich Panels
Steel thickness :
0.4-0.7mm
PU thickness :
50-200mm
Core material :
Hard Polyurethane Foam
PU density :
42KG/m3
Description

Insulated Pur Foam Sandwich Panel Cold room For Warehouse or Pu Sandwich Panel

Packaging & Delivery

1 . Packaging Details : Nude packed in container, and be fixed by plastic packing belt. We can also follow your own requirement.

2 . Delivery Detail : Within 7-20 working days after the payment.

Product Display

The polyurethane cold room panel is composed of two galvanized steel sheets and rigid polyurethane foam in the middle. Because the polyurethane cold room panel has several outstanding advantages, such as thermal insulation, waterproof, light weight and fast installation, It has been widely used as the building material of cold room, cool rooms, clean rooms, free-dust workshops and exterior walls in cold places.

At present, BRD polyurethane cold room panel has five different thickness: 50mm, 75mm, 100mm, 150mm, 200mm.

Item Specification
Product Name Cold Room
Structure PPGI + Polyurethane Foam + PPGI (PPGI : Prepainted Galvanized Steel Sheet)
Effective Width 1000mm
Panel Thickness 50mm 75mm 100mm 150mm 200mm
Length Customized
Core Rigid Polyurethane Foam
Density 42 Kg/m³
Thickness Of Steel 0.4mm To 0.7mm
Color White
Thermal 0.23%w/(m.k) Maximum
Enclosed Rate 95% Minimum
Flame Resistance Grade b
Usage Life Over 20year

Room Temperature For Your Reference:

Store Goods Temperature Range
Processing Room 10℃
Fruit, Vegetable, Dry Food 0℃ ~ 5℃
Medicine, Cake, Pastry, Chemical Material -5℃ ~ 0℃
Ice Storage Room -5℃ ~ -10℃
Fish, Meat Storage -18℃ ~ -25℃
Deep Freezer -25℃ ~ -35℃

FAQ

What Is The Suitable Height Of Cold Room?

The Height Of Room Ceiling Decides The Maximum Height Of Cold Room. Small Cold Room We Often Suggest 2.3~2.8m. Big Cold Storage We Suggest 3~5m.

If We Use Forklift, Can The Cold Room Floor Use Pu Panel?

No. The Compressive Strength Of Pu Panel Is Smaller Than 200kpa, Too Weak To Suffer Heavy Forklift. So We Suggest Xps Floor, With 350kpa Compressive Strength.

What Is The Daily Power Consumption?

Some Factors Such As Environment Temperature, Entering Temperature, Products Quantity Are Objective, Hard To Be Changed. But We Can Provide You With Good Insulation Panels And High Quality Refrigeration Units. These Will Reduce Your Daily Power Consumption.
