Fruit / Vegetable Cold Storage Room With Sliding Or Swing Door One Year Warranty
Fruit / Vegetable Cold Storage Room With Sliding Or Swing Door One Year Warranty
Fruit / Vegetable Cold Storage Room With Sliding Or Swing Door One Year Warranty
Fruit / Vegetable Cold Storage Room With Sliding Or Swing Door One Year Warranty
Specifications
Brand Name :
Green&Health
Model Number :
CR-
Certification :
CCC
Place of Origin :
Guangzhou,China
MOQ :
1pc
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
500/pcs/month
Delivery Time :
delivery in 20-25 days after we received your deposit
Packaging Details :
Crate package
Material :
Painted steel/Stainless steel
Power Source :
Electricity
Air Cooler :
Brand Kewely
Compressor :
Copeland/Famous Brand
Warranty :
One Year
Temperature :
0-10 degree/-18 degree/-30degree
Description

Fruit/Vegetable Cold Storage Room with Sliding Door or Swing Door

Features:

1. Copeland/Famous Brand Compressor.

2. High-thread series of low-temperature DL evaporator

3. Danfoss high-end expansion valve. (Series expansion valve fot freezer, capillary cut for cooler)

4. Full computer control system (automatic control).

5. Cooper piping tube + frozen oil + cooling of the refrigerant 404A +silver eletrode + Insulation.
Condensate water processor.Packing+carton box/wood box+certification

The price is our weapon,quality is our life.To save the cost of investment and operating costs for our client,12
which is the goul that we always work for.For the better quality,We continue to innovate.

Cold Room Panels

Panel thickness we can provide 50mm/75mm/100mm/120mm/150mm/200mm for option,

but most popular thickness is 100mm.Different temperature need different pane thickness.

Temperature we can make it 2~8℃,-18℃,-35℃ and others.

Could you please provide information as below when you send the inquiry:

1. Room size:'m" (Length width heigh)?
2. What kind of goods will put into the room? (fresh or frozen)?
3. Port name and country name? How about industry voltage?
Fruit / Vegetable Cold Storage Room With Sliding Or Swing Door One Year Warranty

Specification

1. Cold Room: Suitable temperature 0℃ (High Temperature)

①Boay material thick: 75mm, door: W0.8*H1.8m

②Copeland/Famous Brand compressor

Cube m³/Dimension Unit power/horse power
10 (2m*2m*2m) 1.5HP
20 (3m*2.7m*2.5m) 2HP
30 (4m*3m*2.5m) 2HP
40 (4m*4m*2.5m) 3HP
50 (5m*4m*2.5m) 4HP
60 (6m*4m*2.5m) 4HP
70 (5.6m*5m*2.5m) 5HP
80 (6.4*5m*2.5m) 6HP
90 (6m*6m*2.5m) 6HP
100 (5m*8m*2.5m) 7HP

2. Frozen Room: Suitable temperature -18℃ (Middle low Temperature)

① Boay material thick: 100mm, door: W0.8*H1.8m

② Copeland/Famous Brand compressor

Cube m³/Dimension Unit power/horse power
10 (2m*2m*2m) 1.5HP
20 (3m*2.7m*2.5m) 2HP
30 (4m*3m*2.5m) 4HP
40 (4m*4m*2.5m) 5HP
50 (5m*4m*2.5m) 6HP
60 (6m*4m*2.5m) 7HP
70 (5.6m*5m*2.5m) 8HP
80 (6.4*5m*2.5m) 9HP
90 (6m*6m*2.5m) 10HP
100 (5m*8m*2.5m) 11HP

3. Quick-freezer, ultra low, temperature -30℃

①Boay material thick: 150-200mm, Size can customize for you


Details:

Fruit / Vegetable Cold Storage Room With Sliding Or Swing Door One Year Warranty Cold Room Panels

1. PU Panels for wall, ceiling and floor
1) Density: 43KGS
2) Cam Lock design
3) Fire resistance According to B2 of GB 8624-1997
4) Packing with Bubble film ​
Cooling Machine

1) American Copeland/Famous Brand refrigeration unit
2) Horse power factory standard
3) Power supply: 220v/380v, 50hz/60hz
4) Air cooled condenser
5) Refrigerant: R404a		 Fruit / Vegetable Cold Storage Room With Sliding Or Swing Door One Year Warranty
Fruit / Vegetable Cold Storage Room With Sliding Or Swing Door One Year Warranty

Air Cooler


1) Brand Kewely
2) fast cooling,auto defrost

Accessories:

Hardware, manual stabilizer, expansion valve, tem-balance window, insulation copper piping, moisture-proof cold light, digital temperature control system and so on

Fruit / Vegetable Cold Storage Room With Sliding Or Swing Door One Year Warranty

Contact way:

Mobile phone/Wechat/whatsapp: 0086-13826182637

QQ: 2355527466
