Threaded Type Special Vehicles Diesel Engine Fire Pump 570 × 510 × 560mm
Threaded Type Special Vehicles Diesel Engine Fire Pump 570 × 510 × 560mm
Threaded Type Special Vehicles Diesel Engine Fire Pump 570 × 510 × 560mm
Threaded Type Special Vehicles Diesel Engine Fire Pump 570 × 510 × 560mm
Specifications
Brand Name :
Jindun
Model Number :
JBQ5.5/12.5-L
Certification :
ISO
Place of Origin :
China
MOQ :
1
Price :
USD
Payment Terms :
T/T
Supply Ability :
300/year
Delivery Time :
3months
Dimension :
570×510×560mm
Net weight :
≤65kg
Highest lift :
75m
Rated pressure :
0.55Mpa
Cylinders :
Double cylinder
Water pump :
Single stage
flow rated :
750L/min
suction depth :
7m
Description

Connection method threaded type Middle pressure middle flow Portable fire pump 570×510×560mm Dimension

Dimension 570×510×560mm
Weight ≤65kg
Rated flow rate 750L/min
lift 75m
Rated pressure 0.55Mpa
Inlet pipe diameter φ65mm
Outlet pipe diameter φ65mm
Water gun nozzle diameter φ19mm
Connection method Threaded type
Maximum suction depth 7m
Water diversion time ≤15s
Startup mode Hand/electric start
Engine type 15HP,LF190FD
Water pump Single stage

Threaded Type Special Vehicles Diesel Engine Fire Pump 570 × 510 × 560mm
