6x4 Drive Foam Fire Truck With Flat Top Metal Forward Turnover Cab Foam 2000kg
6x4 Drive Foam Fire Truck With Flat Top Metal Forward Turnover Cab Foam 2000kg
6x4 Drive Foam Fire Truck With Flat Top Metal Forward Turnover Cab Foam 2000kg
6x4 Drive Foam Fire Truck With Flat Top Metal Forward Turnover Cab Foam 2000kg
Specifications
Brand Name :
HOWO
Model Number :
JDX5280GXFPM120/H
Certification :
ISO9001,CCC
Place of Origin :
shanghai China
MOQ :
1unit
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
90days
Dimension :
9920×2500×3600mm
Gross weight :
27550kg
shipping mass :
14900kg
Seat (inc. driver) :
6
Max. power :
276km
Wheelbase :
4325+1350mm
Description

6x4 Drive Type Foam Fire Truck With Flat Top Metal Forward Turnover Cab Foam 2000kg

Vehicle

Dimension (L×W×H) 9920×2500×3600mm
Gross weight 27550kg
Complete vehicle shipping mass 14900kg
Seat (inc. driver) 6
Max. power 276kw

Chassis

Manufacturer Sinotruk HOWO
Model ZZ5347V4347D5
Drive type 6x4
Cab Flattop metal forward turnover
Wheelbase 4325+1350mm
Max. speed 90km/h
Min. turning diameter <22m
Approach angle 16°
Departure angle 12°

Liquid tank
Capacity Water: 10000kg Foam: 2000kg
Material 304 high quality corrosion resistant plate
Structure Total side girder
Device

2 ingates

1 overflow device

2 liquid level sensor

2 DN50 drain outlet with valve

4 filling pipe end

Conform to rule GA39.4-92

Side girder

Features: made of welding high quality profiled steels, two longitudinal beams through a plurality of beam intensity bearing joint of high strength bolt connection. The side beam is installed, use girder structure, to ensure that the original car beam of uniform stress, improve the service life of the girder, and reduce deformation caused by components twisted.

Dash board and on-board equipment

Cab PTO gear switch

Pump room

Function switch lighting, water outlet, water injection, liquid outlet, monitor shot
Dash board Pressure gauge, Water gauge, vacuum gauge, content gauge, tachometer

6x4 Drive Foam Fire Truck With Flat Top Metal Forward Turnover Cab Foam 2000kg
