FIAT IVECO 4×2 Drive 217 Horsepower 2200L / 500L Water/Foam Fire Truck
FIAT IVECO 4×2 Drive 217 Horsepower 2200L / 500L Water/Foam Fire Truck
FIAT IVECO 4×2 Drive 217 Horsepower 2200L / 500L Water/Foam Fire Truck
FIAT IVECO 4×2 Drive 217 Horsepower 2200L / 500L Water/Foam Fire Truck
Specifications
Brand Name :
IVECO
Model Number :
JDX5080GXFPM30/Y
Certification :
ISO9001,CCC
Place of Origin :
shanghai China
MOQ :
1 unit
Price :
Factory price, Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
90days after sign contract
Supply Ability :
300 units/year
Packaging Details :
Exporting standard package or customized packing
Dimension :
5270mm×2200mm×2980mm
Emission :
China V
Water/ foam capacity :
2200L /500L
Seat (inc. driver) :
2+3
Drive type :
4x2
Max. speed :
110km/h
Tank material :
Stainless steel 304
Product name :
Water and foam fire truck
Description

FIAT IVECO 4×2 Drive 217 Horsepower 2200L / 500L Water/Foam Fire Truck

Electrical system

The main lights in the cab at the top of the long row of lights, public address system with Wail-Yelp alarm whistle, including microphone and 100W loudspeaker. 2 Red and blue alarm lamp on both side. A 70w searchlight is set on the roof of the vehicle.

Vehicle basic data

Dimension (L×W×H) 5270mm×2200mm×2980mm
Gross weight 7800 (kg)
Wheel base 2790mm
Water/ foam tank capacity 2200L /500L
Max. engine power 160kW(217hp)/2700r/min
Emission standard China V
Max. speed 110km/h
Seat (inc. driver) 2+3
Approach angle 18°
Departure angle 30°
Fire pump flow 1.0MPa, 32L/s

Chassis

Manufacturer FIAT IVECO
Model ML 100E22
Driving 4×2
Min. turning radius 5.2m
Min. ground clearance Front 169mm, rear 172mm
Chassis Net weight 10910Kg
Approach angle 18°
Departure angle 18°
Engine IVECO TECTOR 6, F4AE3681B*S
Max. authorized total mass 10000kg
Displacement 5.88L
Max. torque 680N•m/1200~2100r/min
Max. power 160kW (217HP)/2700r/min
Fuel tank 115L plastic fuel tank, 25L heating type urea tank, Recor oil-water separator with heating

Fire pump

Manufacturer HALE
Model AP32
Water flow 1.0MPa 32L/s
Max. suction depth 7m
Priming time ≤35s

Liquid pipe

Capacity Water : 2200L, foam: 500L
Material High quality stainless steel 304
Equipment

1 manhole (450mm)

1 overflow device

1 venting device

2 liquid level sensor

2 drain outlet with valve

2 outside filling pipe end

1 inside filling pipe end

FIAT IVECO 4×2 Drive 217 Horsepower 2200L / 500L Water/Foam Fire Truck
