206kw Manual Gearbox Commercial Fire Bridage Vehicle for Rescue & Fire Fighting
206kw Manual Gearbox Commercial Fire Bridage Vehicle for Rescue & Fire Fighting
206kw Manual Gearbox Commercial Fire Bridage Vehicle for Rescue & Fire Fighting
206kw Manual Gearbox Commercial Fire Bridage Vehicle for Rescue & Fire Fighting
Specifications
Brand Name :
HOWO
Model Number :
JDX5200GXFPM80/H
Certification :
ISO9001/CCC
Place of Origin :
Shanghai,China
MOQ :
1 unit
Price :
Factory price, Negotiable
Payment Terms :
L/C, D/A, T/T, Western Union, MoneyGram, D/P
Supply Ability :
300 units/year
Delivery Time :
90 days after sign contract
Packaging Details :
Nude packing
Dimension :
8475×2500×3400 (mm)
GVW :
19800 (kg)
Seats :
2 + 4
Max. power :
206kw
Drive type :
4x2
Max speed :
100km/h
Wheelbase :
4600mm
Pump Pressure/ Flow :
1.0MPa/60L/s
Transmission :
Manual control
Product name :
Commercial Fire Bridage Vehicle
Description

206kw Manual Gearbox Commercial Fire Bridage Vehicle for Rescue & Fire Fighting

Vehicle

Dimension (L×W×H) 8475×2500×3400 (mm)
Gross weight 19800 (kg)
Complete vehicle shipping mass 11600 (kg)
Seat (inc. driver) 2+4
Max. power 206kw

Chassis

Manufacturer Sinotruk HOWO
Model ZZ5207M4617D5
Drive type 4x2
Cab Four door lengthen cab
Wheelbase 4600mm
Max. speed 100km/h
Min. turning diameter ≤20m
Approach angle 16°
Departure angle 14°
Engine type Pressure combustion, In-line six-cylinder, water cooling, inter-cooling, direct injection diesel engine
Model D10.28-40
Max. torque 1190N.M
Emission standard China IV
Clutch pull type diaphragm
Gearbox Manual, 10 forward gear

Fire pump

Manufacturer SHANGHAI XIONGZHEN
Model CB10/60-XZ
Pressure/ Flow 1.0MPa/60L/s
Primer type Piston primer pump
Max. vacuum degree ≥85 kPa
Priming time ≤50s
Air foam proportioner PH48, manual, mixing ratio:3%, 6%

Side girder

Features: made of welding high quality profiled steels, two longitudinal beams through a plurality of beam intensity bearing joint of high strength bolt connection. The side beam is installed, use girder structure, to ensure that the original car beam of uniform stress, improve the service life of the girder, and reduce deformation caused by components twisted.

206kw Manual Gearbox Commercial Fire Bridage Vehicle for Rescue & Fire Fighting

FAQ

1. Q: Why should we choose you ?

A: a. We are professional manufacture located in Shanghai city for firefighting trucks products which nearby Pudong International Airport, is easily for customer coming and visiting.

b. We can export directly to overseas customer, no need to deal with trading company and the second price increase will not occur.

c. We have our own R&D team, production workshop, QC management team,international marketing team and after service team.

2. Q:What's the delivery time?

A: a. 20 days delivery upon receipt of advance deposit if we have ready in stock for normal standard model.

b. ISUZU & Chinese brand chassis 3 months upon receipt of advance deposit.

c. European brand chassis 9 months upon receipt of advance deposit.

3. Q:What's your payment method?

A: T/T and L/C are preferred.

4.Q:Do you arrange shipment for the vehicles?

A:Yes, we can arrange shippment based on trade terms.

5. Q: How is the packing?

A:All the packing comply with exporting standard.

Any other questions, please do not hesitate to contact with us.
