6x4 Drive Fire Fighting Truck Rotatable Type Cab With Seperate Crew Room
6x4 Drive Fire Fighting Truck Rotatable Type Cab With Seperate Crew Room
6x4 Drive Fire Fighting Truck Rotatable Type Cab With Seperate Crew Room
6x4 Drive Fire Fighting Truck Rotatable Type Cab With Seperate Crew Room
Specifications
Brand Name :
Mercedes
Model Number :
JDX5390GXFPM180
Certification :
ISO9001/CCC
Place of Origin :
shanghai,China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
350 units/year
Delivery Time :
90days
Packaging Details :
Nude packing
Size :
11310×2500×3630mm
G.V.W (kg) :
38650kg
Wheelbase :
1700+4300+1350mm
Max. speed :
95km/h
Drive type :
8x4
seat :
6
Max. power :
440kw
Cab Structure :
Rotatable type
Key words :
6x4 Drive Fire Fighting Truck
Description

6X4 drive six seats Mercedes chassis Foam firefighting truck vehicle Rotatable type cab

PM180 foam fire fighting truck, fire fighting vehicle, foam tanker fire truck is adapted from Mercedes Benz Actros4160 chassis. With 440kw diesel engine and manual control transmission, 16 forward gear. The vehicle equipped with totatable cab and imported fire pump and fire monitor.

Vehicle

Dimension (L×W×H)11310×2500×3630mm
Gross weight38650kg
Complete vehicle shipping mass20600kg
Seat (inc. driver)6
Max. power440kw


Chassis

ManufacturerDaimler
ModelActros4160
Drive type8x4
CabRotatable type
Wheelbase1700+4300+1350mm
Max. speed95km/h
Min. turning diameter≥26m
Approach angle23°
Departure angle11°
Engine typeInline eight-cylinder, four-stroke, water-cooling, electronic direct injection diesel engine
ModelOM502LA.IV/3
Max. power440kw
Max. torque2800N•m
Emission standardChina IV/Euro IV
ClutchMonolithic, dry
Gearbox modelManual, 16 forward gear
Tyre

Forward: 4x 385/65R22.5
Rear: 8x 315/80R22.5


Cab

StructureRotatable type
Seat1+1+4
EquipmentExcept the original equipments. There is a storage box with cover under the seat, embedded air breathing apparatus fixed mount in the seats


Side girder
Features: made of welding high quality profiled steels, two longitudinal beams through a plurality of beam intensity bearing joint of high strength bolt connection. The side beam is installed, use girder structure, to ensure that the original car beam of uniform stress, improve the service life of the girder, and reduce deformation caused by components twisted.

6x4 Drive Fire Fighting Truck Rotatable Type Cab With Seperate Crew Room

FAQ:

1. Q:Are you a factory or a trade company?

A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.

2. Q:Where is your factory located?

A:We are located in Shanghai Province,China.

3. Q:What's your payment method?

A: T/T and L/C are preferred.

4.Q:Do you arrange shipment for the vehicles?

A:Yes, we can arrange shippment based on trade terms.

5. Q: How is the packing?

A:All the packing comply with exporting standard.

6. Q: What's your main product?

A: Our main product include : water & foam tank trucks, CAFS fire trucks, chemical fire trucks, emergency rescue vehicles, lighting trucks, aerial ladder and platform trucks, airport fire trucks, water tower fire trucks and other general fire trucks. The products have been sold to more than 20 countries.

Any other questions, please do not hesitate to contact with us.
