39 Ton Water Tower Fire Truck Imported Chassis Full Authorized Total Mass 31000KG
39 Ton Water Tower Fire Truck Imported Chassis Full Authorized Total Mass 31000KG
39 Ton Water Tower Fire Truck Imported Chassis Full Authorized Total Mass 31000KG
39 Ton Water Tower Fire Truck Imported Chassis Full Authorized Total Mass 31000KG
Specifications
Brand Name :
Jindun
Model Number :
JDX5310JXFJP32
Certification :
ISO9001,CCC
Place of Origin :
Shanghai,china
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
300 units/year
Delivery Time :
90 days after sign contract
Packaging Details :
Exporting standard package or customized packing
Chassis brand :
Mercedes-Benz
Dimension :
10330×2500×3980(mm)
Gross weight :
31000(kg)
Seats number :
2+4
Fording depth :
500mm
Driving :
6x4
Max loading :
23700Kg
Working height :
32 meters
Product name :
39 Ton water tower fire trucks
Description

39 Ton Water Tower Fire Truck Imported Chassis Full Authorized Total Mass 31000KG

JDX5310JXFJP32 fire truck is a combination of water, foam, high jet three functions in a new class of high-lift truck. It is a domestic advanced level of multi-purpose fire fighting vehicles. The car is used electro-hydraulic proportional and off centrally control technology with fully hydraulic drive, three telescopic + folding side arranged a fire truck.

The whole vehicle

Full authorized total mass 31000 kg
Vehicles curb weight 23800 kg
Seats 2 + 4,including the driver
Maximum power 320/435 Kw/hp

Chassis

Manufacturer Mercedes-Benz
Model Mercedes Actros3344
Drive Type 6 × 4
Cab modified Crew (1 + 1 + 4),Rear rack installation four SCBA
Wheelbase 4500 + 1350 mm
Chassis weight 9230Kg
Maximum allowable load 23700Kg
Maximum speed 104Km / h
Engine V-type 6-cylinder turbocharged and intercooled diesel engine
Model Mercedes-Benz OM501 LA
Maximum engine power 320Kw / 1800r / min
Maximum torque 2100N.M / 1080rpm
Emission standard Euro IV
Clutch monolithic, dry type
Transmission Mercedes-Benz G240-16, fully synchronized gearbox.

Fire systems

Fire performance parameters

Water / foam range: ≥65 / 60m

Foam mixer ratio: 6% (manual adjustment)

solution tank

Manufacturing: Shanghai Jindun Special Vehicle Equipment Co., Ltd.

Capacity: Water: 4800Kg Foam: 1900Kg

Material: 304 stainless steel tank, stainless steel top plate 304 patterns;

Structure: damping rubber flexible support, which consists of longitudinal and transverse anti-swing plate is mounted on the sub-frame;

Equipment: 2 individual openings with quick-locking and opening device;

2 level indicator;

2 outfalls, with stainless steel or brass ball valves;

Within a water inlet;

Four external water inlets;

Fire Monitor

Model: AKRON 3578 type fire gun (with nozzle 5177)

Manufacturer: AKRON

Flow rate: 15.5 ~ 80L / s

Pressure: ≤1.0MPa

Cheng shot: water ≥65m, foam ≥60m

Tilt angle: -45 ° ~ + 90 °

Nominal diameter: 100mm

39 Ton Water Tower Fire Truck Imported Chassis Full Authorized Total Mass 31000KG
