Multi-Function 6x4 Drive Dry Powder And Foam Fire Truck 64L/S Roof Monitor
Multi-Function 6x4 Drive Dry Powder And Foam Fire Truck 64L/S Roof Monitor
Multi-Function 6x4 Drive Dry Powder And Foam Fire Truck 64L/S Roof Monitor
Multi-Function 6x4 Drive Dry Powder And Foam Fire Truck 64L/S Roof Monitor
Specifications
Brand Name :
CIMC Jindun
Model Number :
GP100
Certification :
ISO9001,CCCF, TUV, SGS, SCONCAP, PC
Place of Origin :
Shanghai, China
MOQ :
1 UNIT
Price :
Factory price, Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
350 units/year
Delivery Time :
3 months after sign contract
Packaging Details :
Exporting standard package or customized packing
Chassis brand :
Sinotruk Howo
Max. power :
380 HP
Drive :
6x4
Cab structure :
Double cabin with four doors
Crew seats :
2+4
Water capacity :
7000 L
Foam capacity :
2000 L
Dry power capacity :
500kg
Pump flow :
100 L/s @ 10 bars
Fire monitor :
64 L/s
Product name :
Multi-function dry power and foam fire truck
Description

Multi-function 6x4 Drive Dry Power and Foam Fire Truck 64L/s Roof Monitor


The GP100 Dry powder and foam fire truck is our multi-function combined fire truck which adopts our new technologies, new processes, new materials, independent research and development, using Sinotruk Howo ZZ5347V4347D5 chassis, Shanghai CB10 / 100-XZ fire pump, 500kg dry powder system and the use of Chinese reducing valves, and PL64 fire monitor. It is suitable for large and medium-sized cities public security fire brigade, petrochemical companies, ports, wharfs and other professional fire brigades.

Vehicle

G.V.W 34000 kg
chassis weight 9400 kg
Max speed 90km/h
Seat (inc. driver) 6
Max. power 283kw/380Hp


Chassis

Brand Sino truck
Drive type 6x4
Cab double cabin with four doors
Wheelbase 4325+1350mm
Max. speed 90km/h
Min. turning diameter 18.6m
Engine type inline six-cylinder, four-stroke, water cooled, turbocharged and intercooled engine
Model OM502LA.IV/3
Max. power 283kw/380Hp
Clutch Monolithic, dry
Gearbox model Manual,


Cab

Structure Rotatable type
Seat 1+1+4
Equipment Except the original equipments. There is a storage box with cover under the seat, embedded air breathing apparatus fixed mount in the seats


Fire pump

Manufacturer Chinese brand
Model CB10/100
Flow 100L/s
Pressure 1.0MPa
Water diversion Piston primer pump
Max. vacuum degree ≥85 kPa
Priming time ≤80s
Foam proportioner PH64x3
Type Manual
Mixing ratio 3%, 6%


Fire monitor

Model PL64
Position Rear roof
Flow 64L/s
Pressure 0.8 MPa
Range water≥70m ,foam≥60m
Rotation angle

horizontal: 360°,

Pitching: -15° to 80°
Operation type Manual


Multi-Function 6x4 Drive Dry Powder And Foam Fire Truck 64L/S Roof Monitor

FAQ:

1. Q:Are you a factory or a trade company?

A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.

2. Q:Where is your factory located?

A:We are located in Shanghai Province,China.

3. Q:What's your payment method?

A: T/T and L/C are preferred.

4.Q:Do you arrange shipment for the vehicles?

A:Yes, we can arrange shippment based on trade terms.

5. Q: How is the packing?

A:All the packing comply with exporting standard.

6. Q: What's the delivery time?

A: 1) 20 days delivery upon receipt of advance deposit if we have ready in stock for normal standard model.

2) ISUZU & Chinese brand chassis 3 months upon receipt of advance deposit.

3) European brand chassis 9 months upon receipt of advance deposit.

Any other questions, please do not hesitate to contact with us.
