6 Seats 4x2 Drive Rescue Foam Fire Truck With Two Years Warranty Period
6 Seats 4x2 Drive Rescue Foam Fire Truck With Two Years Warranty Period
6 Seats 4x2 Drive Rescue Foam Fire Truck With Two Years Warranty Period
6 Seats 4x2 Drive Rescue Foam Fire Truck With Two Years Warranty Period
Specifications
Brand Name :
CIMC
Model Number :
PM120
Certification :
ISO9001,CCC
Place of Origin :
shanghai China
MOQ :
1 unit
Price :
Factory price, negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
350 units/year
Delivery Time :
180 days
Packaging Details :
roll roll
Dimensions :
9980×2500×3500mm
Full load mass :
33000kg
Seat :
6
Maximum torque :
1390N•m
Drive type :
4x2
Max. speed :
100Km/h
Wheelbase :
4600mm
Engine power :
228kW
Water :
10000kg
Foam :
2000kg
Product name :
6 seats rescue foam fire truck
Description

6 Seats 4x2 Drive Rescue Foam Fire Truck With Two Years Warranty Period

The PM120 rescue foam fire truck is adapted form Man TGM18.290 chassis. 4x2 drive and max speed could reach 96km/h. The large capacity rescue vehicle could carry 10000kg water and 2000kg foam. Equipped with rear pump and foor fire monitor.

Chassis

Manufacturer MAN
Model TGM 18.290
Drive type 4x2
Cab Crew cab
Wheelbase 4425mm
Max. total mass 18000kg
Max. speed 96km/h
Min. turning diameter <15.6m
Engine type In-line six-cylinder, inter-cooling, high pressure common rail, electronic control
Model D0836LFL30
Max. power 213kw
Max. torque 1150N.M
Emission standard China IV
Gearbox model ZF 9S-1310 OD Manual

Equipment tank

Manufacturer SHANGHAI JINDUN
Material Q235A high quality steel combine aluminium alloy sections
Structure Welding, lap structure, skin, floor, interior panels use rust-proof aluminum plane, pedal tread surface, car roof using aluminum patterns.
Equipment compartment door the light quality aluminum alloy, with shutter doors, lightweight and reliable.
Internal structure the inner frame for the introduction of aluminum lap technology, can maximize space utilization and variability within the equipment, users can request allocation of various sliding bracket, carriage, rotating frame, and high strength plastic storage box and so on, the structure from the space utilization, aesthetic appearance, ease of handling equipment have reached the international advanced level.

Side girder

Features: made of welding high quality profiled steels, two longitudinal beams through a plurality of beam intensity bearing joint of high strength bolt connection. The side beam is installed, use girder structure, to ensure that the original car beam of uniform stress, improve the service life of the girder, and reduce deformation caused by components twisted.

6 Seats 4x2 Drive Rescue Foam Fire Truck With Two Years Warranty Period6 Seats 4x2 Drive Rescue Foam Fire Truck With Two Years Warranty Period

FAQ:

1. Q:Are you a factory or a trade company?

A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.

2. Q:Where is your factory located?

A:We are located in Shanghai Province,China.

3. Q:What's your payment method?

A: T/T and L/C are preferred.

4.Q:Do you arrange shipment for the vehicles?

A:Yes, we can arrange shippment based on trade terms.

5. Q: How is the packing?

A:All the packing comply with exporting standard.

Any other questions, please do not hesitate to contact with us.
