Specifications
Brand Name :
CIMC
Model Number :
JY98
Certification :
ISO9001,CCC
Place of Origin :
Shanghai China
MOQ :
1 unit
Price :
Factory price, negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
350 units/year
Delivery Time :
180 days
Packaging Details :
roll roll
Dimensions :
9000×2500×3500mm
Full load mass :
14990 kg
Seat :
6
QTY of rescue tools :
98 sets
Drive type :
4x2
Max. speed :
100Km/h
Wheelbase :
4600mm
Engine power :
228kW
Product name :
Motorized Emergency Rescue Fire Vehicle
Description

4x2 Drive Six Seats Motorized Emergency Rescue Fire Vehicle with 98 Sets Tools

JY98/H5 rescue fire truck is a fire truck modified with ZZ5207N4617E1 chassis. The fire vehicle integrates multi-functions such as demolition, traction, lifting, lighting, etc. It's performance is reliable, its function is applicable, and it is easy to use. It's mainly used in fire bridages , petrochemical enterprises, military, airport and port terminals in large and medium-sized cities. The vehicle provides a good rescue and rescue means for saving people, dealing with traffic accidents and natural disasters on land.

Structural parameters

Dimensions(length × height × width): 9000×2500×3500mm

Vehicle performance

Engine rated power 228kW
Maximum torque 1390N·m
Maximum speed 100km/h
Maximum climbing ability 30%
Maximum braking distance (30km/h initial speed): ≤10m
Wheelbase 4600mm
Tread front:2060; rear:1830 mm
Approach angle 17°
Departure angle 11°

Axle Load Mass Distribution

Full load mass 14990 kg
Front axle load mass 5590 kg
Rear axle load mass 9400kg
Crew members(including driver) 6

Illuminating system

Model SG65-41000G
Lifting Height 6.45m
Terrain clearance ≥7.5m
Control system operating voltage DC24V
Lamp operating voltage 220V
Lamp power 4×1000W
Horizontal rotation angle of the lamp 360°
Vertical rotation angle of the lamp 360°

Generation

Model EH3135
Rated output power 13.5 Kva
Maximum output power 14.5 kva
Power factor 0.8
Voltage 380/220 V
Electric current Each phase 16.5A
Frequency 50HZ
Fuel gasoline
Continuous working hours 6.5 hours

4x2 Drive Six Seats Motorized Emergency Rescue Fire Vehicle with 98 Sets Tools

FAQ

1. Q: Why should we choose you ?

A: a. We are professional manufacture located in Shanghai city for firefighting trucks products which nearby Pudong International Airport, is easily for customer coming and visiting.

b. We can export directly to overseas customer, no need to deal with trading company and the second price increase will not occur.

c. We have our own R&D team, production workshop, QC management team,international marketing team and after service team.

2. Q:What's the delivery time?

A: a. 20 days delivery upon receipt of advance deposit if we have ready in stock for normal standard model.

b. ISUZU & Chinese brand chassis 3 months upon receipt of advance deposit.

c. European brand chassis 9 months upon receipt of advance deposit.

3. Q:What's your payment method?

A: T/T and L/C are preferred.

4.Q:Do you arrange shipment for the vehicles?

A:Yes, we can arrange shippment based on trade terms.

5. Q: How is the packing?

A:All the packing comply with exporting standard.

Any other questions, please do not hesitate to contact with us.
