Heavy Duty 25m Spray Range 18550L Water Tanker Fire Truck 8x4 Chassis Sinotruk
Heavy Duty 25m Spray Range 18550L Water Tanker Fire Truck 8x4 Chassis Sinotruk
Heavy Duty 25m Spray Range 18550L Water Tanker Fire Truck 8x4 Chassis Sinotruk
Heavy Duty 25m Spray Range 18550L Water Tanker Fire Truck 8x4 Chassis Sinotruk
Specifications
Brand Name :
CIMC Jindun
Model Number :
SG250
Certification :
ISO9001,CCC
Place of Origin :
Shanghai,china
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
300 units/year
Delivery Time :
120 days
Packaging Details :
Exporting standard package or customized packing
Dimension :
11865×2500×3800 mm
Gross weight :
39750kg
working height :
25m
Wheel base :
1875+3950+1380 mm
Fording depth :
500mm
Max loading weight :
30090kg
Seat :
2+4
Driving :
6×4
Water :
18550L
Foam :
4000L
Product name :
Heavy duty water fire truck
Description

Heavy Duty High Capacity Water Tank Fire Trucks 8x4 Chassis Sinotruk

Side girder

Features: made of welding high quality profiled steels, two longitudinal beams through a plurality of beam intensity bearing joint of high strength bolt connection. The side beam is installed, use girder structure, to ensure that the original car beam of uniform stress, improve the service life of the girder, and reduce deformation caused by components twisted.




Chassis

Manufacturer Sinotruk HOWO
Model ZZ5437V4667D5
Drive type 8x4
Cab Flattop metal forward type
Wheelbase 1800+4600+1350mm
Max. speed 95km/h
Min. turning diameter ＜30m
Approach angle 16°
Departure angle 13°
Engine type Inline six-cylinder, water inter-cooling, direct injection diesel engine
Model D12.42—40
Max. power 309kw
Max. torque 1820N•m
Emission standard China IV
Clutch Pull, dry
Gearbox model Manual, 10 forward gear

Pipeline

Outlet pipeline

2×DN80 ordinary pressure outlet

1×DN50 ball valve
Suction inlet

1×DN150 suction coupling

1×DN150 pneumatic butterfly valve
Monitor pipeline

1×DN125 monitor pipeline

1×DN125 butterfly valve
Residual water outlet Water cock
Cooling water pipeline The PTO equipped with a cooling water pipeline connected with the in-outlet pipeline.
