Heavy Duty Recovery Road Wrecker Truck Tow Truck Euro 3 With Cummins Engine
Heavy Duty Recovery Road Wrecker Truck Tow Truck Euro 3 With Cummins Engine
Heavy Duty Recovery Road Wrecker Truck Tow Truck Euro 3 With Cummins Engine
Heavy Duty Recovery Road Wrecker Truck Tow Truck Euro 3 With Cummins Engine
Specifications
Brand Name :
YD
Model Number :
SQZ1860HV
Certification :
ISO, CE
Place of Origin :
CHINA
MOQ :
1 SET
Price :
USD
Payment Terms :
T/T, L/C
Supply Ability :
50 SETS PER MONTH
Delivery Time :
30 working days
Packaging Details :
standard package in container
Drive :
4x2
Dimension :
6695x2180x2350
Maximum speed :
80km/h
Fuel tank :
100L
Towing rating :
12000kg
Emission :
Euro 3
Description

Cummins Engine Heavy Duty Recovery Trucks Rotator Wrecker Tow Truck Euro 3

Vehicle parameters
Vehicle Model EHY5090TQZE
Overall dimensions 7450X2300X2650mm Curb weight 5295kg

Chassis parameters
Chassis model EQ1090T9ADJ3AC Chassis brand DONGFENG
Overall dimensions 6695x2180x2350mm Wheel base 3800mm
Front/rear wheel track 1750/1586mm Front/rear suspension 1180/1715mm
Approach/departure angle 22/13° Maximum speed 80km/h
Chassis Manufacturer Dongfeng Automobile Co.,Ltd
Cab Configuration Single row cab,air conditioner,allowable 3 passengers,cab can be flipped
Color White,other color is optional
Engine
Emission Euro 3
Type 4 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling,diesel engine
Rated power 120hp,rated power speed 2800rpm
Displacement 3856ml
Bore x stroke 102x118mm
Manufacturer Dongfeng Chaoyang Diesel Power Co. Ltd.
Tire Size 7.50R16,steel wire tire
Number 6+1 nos
Frame 192mm
Brake Air break, electronic flame out, exhaust brake
Fuel tank 100L,steel
Front axle 2.4T
Rear axle 4.2T
Drive form 4X2
Rated voltage 24V,DC
Transmissions 5 speed forward 1 reverse.
Steering device Power assisted steering
Steering wheel Left hand drive
Selective configuration Air Conditioner, Cummins engine B140 33(140hp)
If there is a slight change in the chassis parameters above,please take the actual product as the standard

Wrecker structure parameters
Equipment 2 units of towing wheel, 1 unit of 4 ton winch, 1 unit of steel wire rope, 1 unit of spare tire, 1 unit of jack, 1 unit of tire sleeve, 4 units of wrecker binding, 1 unit of alarm lamp.
Flat-bed dimensions 5600*2300mm
Flat-bed Max capacity 4000kg
Max under-hoisting capacity 1800kg
Winch numbers 1 unit
Max towing capacity of winch 5000kg
Max towing speed 40km/h
Length of steel wire rope 20m
Speed of steel wire rope 8 m/min

Heavy Duty Recovery Road Wrecker Truck Tow Truck Euro 3 With Cummins Engine
