Electric Defrosting Cold Store Room For Fruit And Vegetables With Volume Of 800 Tons
Electric Defrosting Cold Store Room For Fruit And Vegetables With Volume Of 800 Tons
Electric Defrosting Cold Store Room For Fruit And Vegetables With Volume Of 800 Tons
Electric Defrosting Cold Store Room For Fruit And Vegetables With Volume Of 800 Tons
Electric Defrosting Cold Store Room For Fruit And Vegetables With Volume Of 800 Tons
Electric Defrosting Cold Store Room For Fruit And Vegetables With Volume Of 800 Tons
Specifications
Brand Name :
EASYCOOL
Model Number :
EASYCOOL COLD ROOM
Certification :
CE,ISO9001,SASO,SGS,
Place of Origin :
Guangdong China
MOQ :
1 unit
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
5000 Set/Sets per Month
Delivery Time :
10 working days after getting deposit payment
Packaging Details :
Plywood case pallet for cold room
Material :
Polyurethane foam
Dimension(W*H*Dmm) :
Depend
Voltage :
220V /380V/420V/ 440V
Compressor :
Copeland Bitzer brand
PU panel thickness :
50mm 75mm 100mm 120mm 150mm 200mm
Refrigeration system :
Bitzer , copeland compressor,evaporator ,condenser etc
Cooling approach :
Water cooled or air cooled
Door :
Single swing door
Weight :
Customized
Application :
fruit and vegetables
After warranty service :
Video technical support, Online support, Spare parts
Temp. Range :
-60~+20'C
Warranty :
1 year
Description

Electric Defrosting Cold Store Room For Fruit And Vegetables With Volume Of 800 Tons

Our modular walk in cold storage series is an integrated family of sandwich panels designed for quick cold room assembly. The panel configuration has been reduced to a minimum, so the overall effect is to offer the clients maximum design possibilities for cold rooms with a minimum amount of panels required on the site. All products from the modular range can be easily assembled without the need for special tools.

Our advantage:
1. Over 10 years manufacturing experience, products sell well in many countries, full experience support to give you most suitable system
2. Compressor, we use all new origin famous brand, Bitzer, Copeland, Tecumseh, Maneruop or brand you appointed. other accessories are same,
3. Professional engineer support, can assist you from design to after sale service.


Cold Storage Material Including:
* Insulation Part: Panel, Door, and sealrant glue;
* Refrigeration part: condencing units, air cooler, cooper tube;
* Other part: Wire, light,other accessories,etc.

Specification for Cold room:

Dimension
Length(m)*Width(m)*Height(m)
Refrigeration unit
Copeland/Bitzer etc.
Refrigeration type
Air cooled/water cooled/evaporation cooled
Refrigeration
R404a,R447a,R448a,R449a,R507a Refrigerant can be option
Defrost Type
Electric defrosting
Voltage
220V/50Hz,220V/60Hz,380V/50Hz,380V/60Hz,440V/60Hz optional
Panel
New material polyurethane insulation panel,43kg/m3
Panel thickness
50mm,75mm,100mm,150mm,200mm
Type of door
Hanged door,sliding door,double swing electric sliding door,truck door
Temp. of room
-60℃~+20℃ optional
Functions
Fruit,vegetable,flower,fish,meat,chicken,medicine,chemical,electronics,etc.
Fittings
All necessary fittings are included,optional
Place to assemble
Indoor/out door(concrete construction building/steel construction building)
Electric Defrosting Cold Store Room For Fruit And Vegetables With Volume Of 800 Tons


Cold room PU sandwich panels system

Electric Defrosting Cold Store Room For Fruit And Vegetables With Volume Of 800 Tons

Polyurethane foam is been sandwiched between the two outer skins and hence is known as PU sandwich panels. We are engaged in manufacturing reliable PU sandwich panels in variegated specifications.Those two layers are available in profile with zinc coated, galvanized steel, embossed aluminum, stainless steel or other material sheets.
Density: 40-42kgs/m3
Thickness of PU panels: 50mm 75mm 100mm 120mm 150mm 200mm
Thickness of steel:0.426mm and 0.5mm
Steel material: color steel plate and galvanized steel plate and stainless steel plate.


Electric Defrosting Cold Store Room For Fruit And Vegetables With Volume Of 800 Tons

Electric Defrosting Cold Store Room For Fruit And Vegetables With Volume Of 800 Tons
Refrigeration unit, condensing unit, air cooled cooling system
1.Intergrated modular assembly, factory pre-assembled refrigeration parts and electrical components.
2.Compacted structure, easy to install and maintain.
3.Widely used in restaurants, shops, shopping malls, cold storage and other place.
4.Whole unit needs to install in a shell for accessories protection.
Configuration of condensing unit:
Compressor, condenser, axial fan with external rotor, liquid receiver, HP/LP controller, HP/LP gauge, dry filter, solenoid valve, sight glass, check valve, junction box, etc.
Brand of compressor: Germany Original Bitzer compressor American Original Copeland compressor
Refrigerant: R22, R404A, R134A
Voltage: Customized according to your local power source

Cold room install
Electric Defrosting Cold Store Room For Fruit And Vegetables With Volume Of 800 Tons

Could you please provide information as below when you send the inquiry:

1.Room size:'m" (Length width heigh)?
2.What kind of goods will put into the room? (fresh or frozen)?
3.Port name and country name? How about industry voltage?
