Beef Shrimp Chicken Quick Freezing Cold Room Walk In Freezer Refrigeration Equipment
Beef Shrimp Chicken Quick Freezing Cold Room Walk In Freezer Refrigeration Equipment
Beef Shrimp Chicken Quick Freezing Cold Room Walk In Freezer Refrigeration Equipment
Beef Shrimp Chicken Quick Freezing Cold Room Walk In Freezer Refrigeration Equipment
Specifications
Brand Name :
EASYCOOL
Model Number :
EASYCOOL COLD ROOM
Certification :
CE,ISO9001,SASO,SGS,
Place of Origin :
Guangdong China
MOQ :
1 unit
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
6000 Set/Sets per Month
Delivery Time :
15-30working days after getting deposit payment
Packaging Details :
Plywood case pallet for cold room
Panel Material :
Coated Steel, PU
Dimension(W*H*Dmm) :
Depend
Voltage :
220V /380V/420V/ 440V
Compressor :
Copeland Bitzer brand
PU panel thickness :
50mm 75mm 100mm 120mm 150mm 200mm
Refrigeration system :
Bitzer , copeland compressor,evaporator ,condenser etc
Cooling approach :
Water cooled or air cooled
Door :
Single swing door
Weight :
Customized
Application :
Beef storage
After warranty service :
Video technical support, Online support, Spare parts
Temp. Range :
-30~+10'C
Warranty :
1 year
Description

Beef Shrimp Chicken Quick Freeze Cold Room Walk In Freezer Refrigeration Equipment

Cold Room full set includes: compressed air cooler + temperature control system + condensing unit + spare parts.

Cold Room Panel Information
Material Core Material Polyurethane
External Material Painting steel sheet/SS/Aluminum/Galvanized sheet(Option)
Thickness Core Thickness 100mm, 120mm, 150mm, 200mm(Option)
Extenal Thickness 0.726mm-1mm
Cold Room Panel Density 42KG/Cubic Meter
Compressor Brand Panasonic, Copeland, Bitzer(option)
Fire Rating B2, (B1 is coming soon)
Bonding Strength ≥0.100MPa
Fruit, Vegetable, Seefood Suggest 100mm, and temperature -5℃ to 20℃
Fish,Chicken, Beef, Mutton, Seafood Suggest 150mm, and temperature -18℃ to -25℃
Quick frozen meat, seafood, Suggest 200mm, and temperature -35℃ to -40℃

Beef Shrimp Chicken Quick Freezing Cold Room Walk In Freezer Refrigeration Equipment

Cold Room Door:

Beef Shrimp Chicken Quick Freezing Cold Room Walk In Freezer Refrigeration Equipment

1.PU sandwich panel cold room door
2.Good heat preservation performance
3.Thickness:100mm/150mm/200mm
4. Classification: manual or electric sliding door, manual swing door,self-closing door, industrial sliding door,half buried door and other types according to customers.
5.Easy to install

Cold room panel:
Beef Shrimp Chicken Quick Freezing Cold Room Walk In Freezer Refrigeration Equipment

Temperature recommend

Cold room function Designed temperature range
°C °F
Fresh keeping 0 ~ + 5 32~+41
Quick freezing/blast freezing cold storage -40~-35 -40~-31
Processing area e.g. processing, corridor, loading, +2~+8 +35.6~+46.2
Pre-cooling room/chilling room 0 +3~+2

Condensing Unit:

Beef Shrimp Chicken Quick Freezing Cold Room Walk In Freezer Refrigeration Equipment

1.Independently developed Intelligent Controller
2.Advanced Fuzzy Control of Electronic expansion Valve
3.Intelligent on demand hot air defrosting, condensing fan speed regulation
4.Fault self-diagnosis function
5.Intelligent alarm system

Air Cooler:
Beef Shrimp Chicken Quick Freezing Cold Room Walk In Freezer Refrigeration Equipment

1.Scientific design improves the heat exchange efficiency.
2. The shell is made of high-quality galvanized sheet spray or stainless steel,which is corrosion-resistant and beautiful in appearance.
3.Hig-quality stainless steel electric heating tubes are distributed on the evaporator core and the water tray ,and thr defrosting effect is good

Our projects:

Beef Shrimp Chicken Quick Freezing Cold Room Walk In Freezer Refrigeration Equipment

Beef Shrimp Chicken Quick Freezing Cold Room Walk In Freezer Refrigeration Equipment

How to buiding a cold storage room?

- Constructed of 100 mm thick Cold Storage Room panels insulated with polyurethane foam at a density of 38-45 kg/m³.


- Cold Room Panels can be assembled in any size or shape by means of interlock cam system that ensures a very rigid construction and enables dismantling the store to change the size of the entire store room or to facilitate the transportation to other sites.


- Panels are provided with a plastic rim all around. Rubber gaskets ensure air-tightness at all times and perfect thermal insulation. This also means low running costs and no exterior condensation of the panels.


- Exterior and interior are made of galvanized pre-painted anti-fungus and anti-bacteria.(Painting steel will be better) .
