Specifications
Brand Name :
ZXT
Model Number :
ZXT-WP215AT
Certification :
CE/Rohs/FCC
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
3000pcs per month
Delivery Time :
5~10 working days after your confirmation
Packaging Details :
Inner package Packed in carton, reinforced with wooden case as outer package
Screen Size :
21.5 inch
Resolution :
1920X1080
Touchscreen Type :
6 points Infrared Touchscreen
Colorful standard :
PAL/SECAM
Channel quantity :
ATV(200CH)
TV Input :
75 Ω
Description

Win10 System Infrared Touch Screen LCD Monitor with VGA/HDMI/DVI input

1, Main Features :

1), Metal Case Enclosure Design.

2), Cost effective price with high quality LED Screen.

3), with 6 points infrared Touchscreen(option multi-points 2/4/10/16/32 points)

4), Support media contents like video,pictures,flashes etc.

5), Intelligent operation system, easy and fast operation.

6), Support for remote network control.

7), All-in-one, to meet diverse application requirements.

8), Independent research and development of hardware and software.

2, Product introduction :

This kind machine is a normal LCD Monitor with touchscreen function. with multiple input signals port, VGA/HDMI/USB/AV, Besides, you can connect the touchscreen monitor with extra PC. Actually, you can see this kind product around you here and there. Some one special application software installed on this kind machine, you can touch the screen to query some information from web page or perform an operation via software. As you seen, interactive Application represent a major trend in the futures market.

Touch screen technoloy draws attention of audience and keeps them there while you delivery your message. Responsive technology works wonders for engaging customers, and giving you a better opportunity to reach them with your advertising.Interactivity encourages sales, and our monitor's durable design will ensure that your advertsing investment will produce captivating results for years to come.

3, The specification of Touchscreen Panel


We usually default infrared touchscreen panel(2 points) with these feature for our machine as follows :

1, Super Touch speed up to 300 dots/second(3ms) brings you an experience of free touch .
2, Function of automatic detecting and correcting guarantees stable working within 2 seconds once any equipment failure is caused by strong interface.
3, Positioning precision is limited within 1mm thanks to adapting of D precision promoting technology and Automatically compensate the touch sensing at four edges, making touching at edges easier.
4, Supporting automatical adjusting of touch according to dust, making less impact caused by dust.

Win10 System Infrared Touch Screen LCD Monitor with VGA/HDMI/DVI input

Touch Max Resolution 4096 X 4096
Transparency >90% ; Up to 100%
Scanning Speed >50s scans/S
Response speed <12m
Touch type Horizontal Multiple Dot Touch screen
Touch precision 0.625mm
Min Touch object 5m
Touch intensity Over 60,000,000 Single Point Touch
Operation System Win7 or Win8.1,Win10
Operating Voltage DC, 5V 5%
Power Supply Keyboard Serial Interface
Power <1W(Current < 200mA)
Communication RS-232 interface Port, USB port
Vandal-Proof Steel Ball (Diameter 63.5mm 1040g weight) drop from 1040mm , No break
Temperature Operating below 41℃~70℃
Temperature Storage below 50℃~85℃
Altitude 3000m
Noise None
Life Time >10 year

Win10 System Infrared Touch Screen LCD Monitor with VGA/HDMI/DVI input

4, The Product Specification

Screen Parameters Panel size 21.5"
Display area(mm)/mode 476(H) X 268(V)
Maximum resolution 1920 X 1080
Display color 16.7M
Pixel Pitch(mm) 0.282(H)×0.282(V)
Brightness (nits) 350cd/m2
Contrast 1000:1
Visual angle 178/178/178/178°
Response time 8ms
Life(hrs) 50,000(hrs)
TV Parameters Colorful standard PAL/SECAM
Channel quantity ATV(200CH)
TV Input 75 Ω
RF connection type IEC
Hi-frequency interface 1
AV in(yellow) 1
AV out(yellow) 1
YPbPr(green bule red) 1
Multi media 2
HDMI interface 2
Voice output power 8W + 8W
Speaker quantity 2
Surround sound Y
Y V-SC
Front interface USB Host 1
USB Touch 1
HDMI 1
Power supply Power Supply AC 100~240V
Max Power Consumption 90W
Standy Power Consumption 0.3W
Working Condition Working Temperature 0℃ ~ 40℃
Storage Temperature below 20℃~60℃
Working Humidity 10%~90%
