Specifications
Brand Name :
LFL
Model Number :
PL-3D5-6MD
Certification :
CE RoHS
Place of Origin :
Xiamen ,China
MOQ :
200
Supply Ability :
3000pcs per day
Delivery Time :
10-18working days
Packaging Details :
color box , 50pcs in one carton box
light source :
LED
Material :
Aluminum
LED chips :
2835 epistar
Applying :
Embeded
Size :
D100*H20
Hole dimension :
d50-100mm
Power :
6W
Voltage :
86-264V
CRI :
80
lumen output :
350
Beam Angle :
120&Deg.
Life Span :
15000hrs
Description

UFO and down light all in one 6W -20W with free cut hole or lamp base

Product features
1. Using high lumen SMD light source high intensity aluminum shell,fast heating.
2. Using good reflectivity super thin, super bright LGP which make the lights more equally.
3. Low voltage and constant current driver, no glare the light is soft.
4. Launch in 0.01sec, no flashing, no noise, no radiation. Energy saving,and environmental.
5. This product can show high brightness, without seeing the lamp itself.

Suitable for
Household, exhibition hall, hotel, shops,jewelry store, museums, stores and recreational space,etc

UFO And Down Led Round Panel Light All In One 6W -20W With Free Cut Hole Or Lamp BaseUFO And Down Led Round Panel Light All In One 6W -20W With Free Cut Hole Or Lamp BaseUFO And Down Led Round Panel Light All In One 6W -20W With Free Cut Hole Or Lamp Base

UFO And Down Led Round Panel Light All In One 6W -20W With Free Cut Hole Or Lamp BaseUFO And Down Led Round Panel Light All In One 6W -20W With Free Cut Hole Or Lamp Base

Power LEDs Diameter Hole size Voltage PF CRI light efficiency CCT
6W 57D 90mm 75mm 175-265 0.5 70 100/w 2700-7000
12W 93D 120mm 75-105mm 175-265 0.5 70 100/w 2700-7000
18W 165D 170mm 95-155mm 175-265 0.5 70 100/w 2700-7000
24W 240D 220mm 95-205mm 175-265 0.5 70 100/w 2700-7000

A. Easy replacement : Can be suitable to the any cut hole size from D75-D205 .
B. Diffuser plate: PCmaterial from Japan Mitsubishi is used. The 1.5mm ultrathin diffuser pate has a light transmittance of up to 92%, and gentle light diffusion can effectively reduce fatigue and create the light environment.
C. Light guide plate: using Mitsubishi material, thickness 4mm with high precision laser dot, make the light even and comfortable, no dark space, can effectively protect the eyes.
D. Reflective sheeting(round and fan-shape): the Hp LCD TV backlight reflective sheeting has superstrong light reflection,with thickness of 0.25mm-0.55mm.
E. Placed cashions: the soft polyurethane foam rubber, sealing, good elastic memory, high temperature resistant, fire retardant, effectively fixed lamp body internal optical components.
F. Rear cover: 0.8mm iron back cover, dumb white,fine Elizabeth Barbara ohm two kind of spraying process, spray evenly overall sense.
G. Driver: low-voltage constant-current intelligent IC driver is used, which is of integated desing and make of the imported PC maderial,with dust prevention, compression resistance and high temperature resistance. Ambient temperature for working:-20°C-85°C

Specifications
1. SMD 2835
2. 65lm-75lm/w, CRI>80
