Anti - Corrosion Outdoor Disconnect Switch Good Conductivity 40.5kv High Voltage
Anti - Corrosion Outdoor Disconnect Switch Good Conductivity 40.5kv High Voltage
Anti - Corrosion Outdoor Disconnect Switch Good Conductivity 40.5kv High Voltage
Anti - Corrosion Outdoor Disconnect Switch Good Conductivity 40.5kv High Voltage
Specifications
Brand Name :
Tianan Electric
Model Number :
GW4-40.5
Place of Origin :
China
MOQ :
1set
Price :
Pending
Payment Terms :
L/C, T/T, D/A, D/P
Supply Ability :
5000 sets per year
Delivery Time :
30 work days
Packaging Details :
International standard package
Rated voltage :
12kv35kv40.5kv
Usage :
Outdoor
Rated Current :
630A
Mechanical Endurance :
2000times
Description

MonopoleType 40.5kv High Voltage Disconnect Power Isolator Switch in outdoor

General

GW4-40.5 series outdoor high voltage disconnector used for open of closing circuits under voltage but no-load condition in 12KV outdoor electrical system. It has fixed drawhook and self-locking device, effect operation with insulating hook-stick. Anti-pollution type can effectively solve flash due to pollution during the operation to satisfy the requirement of users in strong pollution area.

Environmental Conditions

  • Suitable Altitude: 1000m
  • Suitable Temperature: -45℃ ~ +40℃
  • Relative Humidity: Daily mean ≤95%, monthly mean ≤90%
  • No conductivity dust.
  • No insulation object with devastating metal and corrosive gas.
  • No violent vibration and striking.
  • No explosive danger and fire.

Main Features

  • High ability of anti-corrosion. All exposed steel parts are hot-dip galvanized; shaft pins are made of stainless steel; the surface of aluminium conductor is passivated; standard parts are hot-dip galvanized or made of stainless steel.
  • Reliable and stable drive. Adapters on driving part consist of clamping forks or joint ball shaft; shaft base is in fully-enclosed structure; Three-phase ganged operation is rezlized through touching connection with universial friction.
  • Good conductivity. Touch between outgoing pad contact piece and conductive rod is constructed by flexible connection; Outer-pressed stainless steel spring is used on contact piece; contacting part is silver-plated by finishing process.
  • Good property of operating mechanism.
