1.4m3 Shovel Wheel Loader For Safty Fasten Transportation Delivery 3 Units In 40HQ Container
1.4m3 Shovel Wheel Loader For Safty Fasten Transportation Delivery 3 Units In 40HQ Container
1.4m3 Shovel Wheel Loader For Safty Fasten Transportation Delivery 3 Units In 40HQ Container
1.4m3 Shovel Wheel Loader For Safty Fasten Transportation Delivery 3 Units In 40HQ Container
1.4m3 Shovel Wheel Loader For Safty Fasten Transportation Delivery 3 Units In 40HQ Container
1.4m3 Shovel Wheel Loader For Safty Fasten Transportation Delivery 3 Units In 40HQ Container
Specifications
Brand Name :
MCLLROY
Model Number :
MCL946G
Certification :
CE/ISO
Place of Origin :
China
MOQ :
1 Unit
Price :
$4000-6000/
Payment Terms :
30% T / T in advance and 70% balance before shipment / 100% L / C at sight
Supply Ability :
100 Units / Month
Delivery Time :
5-8 days
Packaging Details :
Nude,Fasten Packing ,2 or 3 Units loaded in one 40HQ
Engine Mode :
Yunnei 4102 Supercharged
RPM :
2400
Rated Power :
76 kW
Emissions :
EU Stage II
Operating Weight :
6350 kg
Rated Load :
2200-2500 kg
Bucket Capacities :
1.4 m³
Max. Travel Speed :
45 km/h
Gear Box :
CVT 300 split torque converter
Axle :
Large hub
Axle Base :
2600 mm
Brake :
Air Brake
Hydraulic Cycle time - lift :
≤ 10 s
Min. Ground Clearance :
370 mm
Wheel Base :
2100 mm
Reach at Max.Dump Height :
3600 mm
Dump Reach :
1180 mm
Overall Length - With Bucket :
6660 mm
Overall Width :
2300 mm
Overall Height :
3000 mm
Tyre Size :
16/70-24
Joystick :
Machanical
Min. turning radius :
5500 mm
Hour meter :
Yes
Tool Box :
Yes
Dual Hight&Low Speed Handle :
Yes
Air Conditioning/heater :
Option
Quick Change :
Option
Multifunctional Attachment :
Option
Hydraulic Pilot :
Option
Extended Lifting Arm :
4.8m Dump Height
Engine Cover :
Electrical Upturned
Description

Shovel Wheel Loader For Safty And Fasten Transportation And Delivery 3 Units In 40HQ Container

1. Products Description of MCLLROY Wheel Loader

In general, for construction machinery, the four most important factors are: price, quality, operation, and after-sales.

The amount of shovel material and the stability of the loader depend on the cooperation of the loader frame.

The flexibility and light operation mainly depends on the hydraulic system of the loader.

The low failure rate depends on quality as well as the after-sales service.

MCLLROY wheel Loaders are widely used in the construction, municipal engineering, urban and rural gardens, lime, sand, cement factories, mines and other enterprises and institutions and departments. It is particularity applied to the narrow space for the loading operation of stone,sand and other construction materials.

2. Specification of MCLLROY Wheel Loader

MCL946G Metric Units
Engine Model Yunnei 4102 Supercharged
RPM 2400
Rated Power 76 kW
Emissions EU Stage II
Operating Weight 6350 kg
Rated Load 2200-2500 kg
Bucket Capacities 1.4 m³
Max. Travel Speed 45 km/h
Gear Box CVT
300 split torque converter
Axle Large hub
Axle Base 2600 mm
Brake Air Brake
Hydraulic Cycle time - lift ≤ 10 s
Min. Ground Clearance 370 mm
Wheel Base 2100 mm
Reach at Max.Dump Height 3600 mm
Dump Reach 1180 mm
Overall Length - With Bucket 6660 mm
Overall Width 2300 mm
Overall Height 3000 mm
Tyre Size 16/70-24
Joystick Machanical
Min. turning radius 5500 mm
Hour meter Yes
Tool Box Yes
Dual Hight&Low Speed Handle Yes
Air Conditioning/heater Option
Quick Change Option
Multifunctional Attachment Option
Hydraulic Pilot Option
Extended Lifting Arm 4.8m Dump Height
Engine Cover Electrical Upturned


3. Details and Advantages of MCLLROY Compact Wheel Loader

1) Stable and proven hydraulic system with triple-wire hydraulic hoses for short cycle times and efficient operation.

2) With an anti-rollover cab, safety, guaranteed.The use of high pressure tempered glass makes it less likely that people will be injured even if the glass breaks.

3) Ergonomic adjustable seat for less fatiguing driving.

4) The general dashboard and integrated hydraulic operating lever design make driving simple and easy to handle.

4.Delivery of MCLLROY Wheel Loader

In addition to stability, we also need to consider as many packs as possible. Since the outbreak of the COVID-19, ocean freight prices have increased significantly, and it is common to see increased costs due to increases in ocean freight rates.

In order to save the buyer's transportation cost, MCLLROY has optimized and improved the size of the loader according to the size of the container. On the premise of reducing customer disassembly procedures as much as possible, install as many as possible.

3 Units 918/926/930/932 can be loaded in a 40HQ container

2 Units 936/940 can be loaded in a 40HQ container
