DONALDSON Hydraulic Oil Filter Cartridge
DONALDSON Hydraulic Oil Filter Cartridge
DONALDSON Hydraulic Oil Filter Cartridge
DONALDSON Hydraulic Oil Filter Cartridge
DONALDSON Hydraulic Oil Filter Cartridge
DONALDSON Hydraulic Oil Filter Cartridge
Specifications
Model Number :
P566188
Packaging Details :
Carton, Wooden cases, Plastic bag, etc, make the package as your requirement.
Place of Origin :
China
Brand Name :
QINGDAO FUTAI
Certification :
ISO 9001:2015
Product Name :
Hydraulic Oil Filter Cartridge
Part Number :
P566188
Application :
DONALDSON Hydraulic Filtration
Material :
Fiber Glass
Filtration efficiency :
99.90%
Working Pressure :
10-210 bar
Warranty :
6 Months
Description

DONALDSON Hydraulic Filtration P566188 Hydraulic Oil Filter Cartridge

Hydraulic oil filter plays an important role in ensuring trouble-free operation of hydraulic system. High performance filters ensure the cleanliness of hydraulic fluids throughout their service life.

DONALDSON P566188
Seal Material Nitrile/Cellulose
Outer Diameter 189.1 mm (7.44 inch)
Inner Diameter 123.44 mm (4.86 inch)
Length 558.8 mm (22 inch)
Efficiency Beta 1000 5 micron
Collapse Burst 6.9 bar (100 psi)
Style Cartridge
Series HRK10
Media Type Synthetic

​Features

  • It can be used for high pressure section, medium pressure section, oil return section and oil absorption section.
  • Wide choice of filtering accuracy. High filtration accuracy is 2-5um, medium filtration accuracy is 10-15um, and low filtration accuracy is 15-25um.
  • The membrane is a fold-type deep-layer filtration, and the membrane filtration area is large. The pleating height of hydraulic oil filter is generally below 20m.

  • Low pressure difference, strong dirt holding capacity and long service life. The pressure difference of hydraulic oil filter is generally 0.35-0.4mpa.

  • High temperature resistance can withstand 135℃.

Hydraulic Filters — Reliably Protect Your Systems and EquipmentDONALDSON Hydraulic Oil Filter CartridgeDONALDSON Hydraulic Oil Filter Cartridge​
