33 Head 1000rpm Quilting Embroidery Machine For Car Seat Cover
33 Head 1000rpm Quilting Embroidery Machine For Car Seat Cover
33 Head 1000rpm Quilting Embroidery Machine For Car Seat Cover
33 Head 1000rpm Quilting Embroidery Machine For Car Seat Cover
Specifications
Brand Name :
Yuxing
Model Number :
YXH-128-50.8B
Certification :
CE
Place of Origin :
China
MOQ :
1 Sets
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
30 Sets/month
Delivery Time :
20 Days
Packaging Details :
Export packing
Dimension :
5.4m*1.4m*2m
Work width :
3.2m
Work speed :
1000rpm
Needle qty :
66pcs
Needle space :
50.8mm
Quilting thickness :
20-600gsm
Description

33 Head Industrial Quilting Embroidery Machine For Car Seat Cover 1000rpm

Application:
The machine is widly used for garments, quilts,blanket, bedspread, handbags, pillow case, car seat , foot pad , car pad, etc.

Functions:
1. The machine works quilting and embroidery together.
2. Y direction adopts roller transmission.
3. The tension motors can keep fabric smoothly feed-in and feed-out. It can keep fabric tightly on production to get precise quilting effect.
4. X,Y,Z direction adopt the servo control system,to ensure the accuracy of embroidery.
5. When thread running out or thread broken, machine will auto stop.
6. The quilting embroidery machine auto-returns to patch-up the unfinished embroidery designs.
7. The automatic refueling system can prolong the machine's life span.
8. Single needle control, easy to select different head working together for different design effect.
9. Continuously quilting independent patterns function,jump and tack quilting function.
10. Tajima,Barudan,ZSK and SWF formats are readable..
11. The unique mechanical structure can reduce the vibration,thereby its better to control the vibration and reduce noise.
12. Machine has power-off protection ,power-off meoory function

Products specification

Machine TypeModel

Head
Quantity

Needle distanceNeedle Quantity of Each HeadEmbroidery AreaSize
Max. work widthL(mm)W(mm)H(mm)
Single needle controlYXH-128-50.8B3350.823400540014002000


Parameter:

Product NameComputer Quilting and Embroidery Machine
ModelYXH-128-50.8B
Dimension (L*W*H)5400*1400*2000mm
Gross Weight3 tons
Quilting width3.35m
Needle space 2 inch
X-stroke260mm
Head quantity33pcs
Shuttle sizeBig rotating shuttle
Quilting thickness20gsm-600gsm
Stitch sizeBinary system:0.15-12.7mm
Needle storage capacity120,000
Pattern storage capacity960
Needle model#14,#16
Principal drive typeServo motor drive
Voltage(AC)3 phase 380V/50HZ,/220V/60HZ
Power supply5KW


Warranty
1 year warranty since container arrives at the destination port. During warranty, machine parts can be replaced for free(except the wearing parts).

Designs
33 Head 1000rpm Quilting Embroidery Machine For Car Seat Cover33 Head 1000rpm Quilting Embroidery Machine For Car Seat Cover
