Z790 Motherboard Intel 12th GEN 2 DDR4 For Gaming Motherboard
Z790 Motherboard Intel 12th GEN 2 DDR4 For Gaming Motherboard
Specifications
Model Number :
Z790-9M2-ICT V1.1
Packaging Details :
Carton box
Delivery Time :
5-8 working Days
Supply Ability :
10000pcs/Day
Model Name :
Z790-9M2-ICT V1.1
Form Factor :
ATX
Memory Type :
DDR4
CPU :
Intel 12th generation CPU, TDP: 125 W.
Description

l Based on Intel Raptor Lake Platform design

l Support for Intel desktop 12th generation processors

l Support dual-channel DDR4 memory/maximum support 64GB/3200MHz.

l 9× M.2 slot (NVME mode only)

l The rear IO provides 10xUSB3.0；; 2xUSB2.0

l Built-in 2 USB2.0 interfaces

l 1 x HDMI 1.4A

l 1 x Gigabit network card, supporting PXE and network wake-up function.

l Support 8+24PIN ATX power input.

Model Name

Z790-9M2-ICT V1.1

Motherboard chip

Intel Z790

CPU

Intel 12th generation CPU, TDP: 125 W.

Optional: I3-12100; I5-12600K; G6900; I5-12500

memory

2*DDR4/3200MHz/64G, single slot can support 32G at most.

Cunzhu

9*M.2 slot (NVME mode only)

Display interface

1*HDMI 1.4A interface

network

1*RJ45 interface

Network card chip

Realtek RTL8111H Gigabit NIC Chip

audio frequency

1*Mic-in； 1* Line-out； 1*Line-in； F_Audio built-in pin

Audio chip

Realtek ALC897 HD Audio Chip

Usb interface

IO interface: 10 * USB 3.0; 2*USB2.0； Built-in 2*USB2.0

Functional pin

1*FPANEL panel pin; 1*4Pin CPU fan; 1*4Pin SYS fan

Power input

8+24Pin ATX power supply

product size

Thin Mini-ITX motherboard specification, 190 mm x 234 mm x 6L.

Working temperature

-10℃~60℃

Working humidity requirements

10%~90% without condensation

Storage temperature

-25℃~70℃

power consumption

Standby power consumption: 13.3W Full load power consumption: 98.8W w.

other

1*3Pin JCMOS jump cap; 1*3Pin JAT jump cap; 1*4Pin SPEAK buzzer
