Specifications
Model Number :
A88X+FM2-V2.11
Place of Origin :
China
Model Name :
A88X+FM2 V2.11
processor :
AMD FM2/FM2+ series processors
Southbridge :
A88X Chipset series
memory :
2 * 240Pin DDR3 1066/1333/1600MH 16GB max
M.2 :
1 SATA M.2
Physical size :
171MM X 220MM
Packaging Details :
Carton box
Delivery Time :
5-8 working Days
Supply Ability :
10000pcs/Day
Description

FM2+ A88 A68 Motherboard DIMM M.2 SSD A10 A8 A6 A4 Motherboards

Features (product features)

▲ Support AMD FM2/FM2+ series processors.

▲ Support 4 SATA interfaces and 10 USB interfaces.

▲ Support technology high-speed DDR3 dual-channel memory slot: support 1066/1333/1600MHz, with a maximum capacity of 16G memory.

▲ Supports 5.1-channel ALC662 chip.

▲ support M.2 SLOT*1

▲ Support high-speed USB3.0 interface transmission speed to increase again.

▲ Support for PCIE expansion slots *2

▲ Support RJ45 Gigabit NIC interface.

▲4-layer PCB backplane with 3+2 phase power supply.

▲ Support Win7 and Win10 32/64 bit operating systems.

Model Name

A88X+FM2 V2.11

processor

AMD FM2/FM2+ series processors.

Southbridge

A88X Chipset series

memory

technology

Dual channel DDR3 1066/1333/1600MHz

maximum capacity

16GB

Memory slot

2 * 240Pin DDR3

Post I/O

PS/2 interface

1 (PS/2 mouse, PS/2 keyboard)

Display interface

1 VGA；; 1 HDMI

USB port

2 USB 3.0；; 2 USB 2.0

Ethernet

1 Realtek Gigabit NIC

Audio

1 (Mic-in, Line-out, Line-in)

Internal connector

USB 2.0

4 (one FUSB can transfer out two USB 2.0 interfaces);

USB 3.0

2 (one FUSB can switch out two USB 3.0 interfaces);

M.2

1 SATA M.2

PCIe

2 (1 PCIe x16；; 1 PCIe x1)

ATXPWR interface

1 standard 1x8PIN power socket; 1 standard 1x24PIN power socket

Audio

1 x 2x5Pin pin

Physical size

measure

171MM X 220MM
